Key Features:
7-inch high-resolution 1024x600 color touch screen, offering users a rich visual experience, easy operation, and at your fingertips.
Virtual Programmable Buttons — Dynamically displays 4 pages, each page can be set to show the status of 28 DSS keys, supporting custom configuration of 112 DSS keys. Each DSS key can be set as Line/BLF/Direct Dial to Extension, etc.
20 SIP lines.
High-definition video (local 720P/remote 1080P).
Gigabit Ethernet — Adaptive 10/100/1000Mbps network port, offering high-speed data transmission, and supporting PoE power supply.
Supports H.264 video decoding, can bind cameras, video access control, conduct video calls, view access control video through the main screen of the phone, and achieve remote door opening and other applications.
High compatibility — Compatible with mainstream SIP-based IPPBX/softswitch/IMS platforms.
Handle / Hands-free / Headphone mode.
Local Telephone Directory (2000 entries), Network Telephone Directory (supports Huawei Unified Directory/XML/LDAP, 2000 entries).
Contact/Call Smart Search.
Call Logs (Unanswered Calls/Incoming Calls/Outgoing Calls, 1000 Entries).
Blacklist / Whitelist.
Screen Saver on Standby.
Automated deployment and configuration (Auto-Provisioning) via FTP/TFTP/HTTP/HTTPS/DHCP OPT66/SIP PnP/TR-069.
Voice Mail (MWI)
Network Time Synchronization
Video and audio recording (local recording / local call recording / server call recording).
Action URL / Active URI。
uaCSTA。
Dialing rules.
SIP Hotspot.
Distinguish ringtones and customize alerts.
Multicast.
Action Plan l Time Plan。
Web management interface, supports web page upgrades.
Supports third-party APPs.
Supports encrypted download of configuration files (AES).
Android System Features
Android OS 9.0 – A safer, more compatible system.
Built-in Apps: File Manager, Calendar, Camera, Gallery, Web Browser, Email, Calculator, Notepad, Recorder, Clock, Video Player, Music.
Supports installation and operation of third-party applications.
二次开发 API:二次开发 Application Programming Interface
Voice Communication Feature
Dialing/Answering/Rejecting, Mute/Unmute (Microphone), Call Hold/Resume, Call Waiting, Intercom Function, Caller ID, Speed Dial, Anonymous Call, Call Forwarding (Unconditional/Busy/No Answer), Call Transfer (In/Out of Office), BLF/Seize, Call Park/Seize (Server-dependent), Redial, Do Not Disturb, Auto-Answer, Call Back, Conference Call, Hotline/Warm Line, IP Direct Dial, Shared Phone (Hot Desking).
Video Features
Video Decoding: H.264.
Video Call Resolution: QVGA / CIF / VGA / 4CIF / 720P / 1080P.
Image Formats: JPEG/PNG/BMP.
Video Format: MP4.
Broadband Range: 64kbps to 4Mbps, Video Frame Rate: 5 to 30fps, Remote Video Full-Screen Display Mode.
Video calls.
Built-in Camera: 2 megapixels, adjustable video angle.
Video Preview.
Audio Features
High-definition Handle/Hold (Handle/Hold, 0 ~ 7kHz Frequency Response).
16KHz sampling for Broadband ADC/DAC.
Narrowband Encoding: G.711a/u, G.729AB, iLBC.
Broadband Coding: G.722, Opus full-duplex hands-free calling, supports acoustic echo cancellation (AEC).
Noise Reduction (NR)
Packet Loss Compensationncealment )。
Dynamic Adaptive Jitter Caching.
DTMF: In-band audio, out-of-band – DTMF relay (RFC2833)/SIP INFO.
Network Features
10/100/1000Mbps Ethernet (bridging mode).
IP Mode: IPv4.
IP Acquisition Method: Static IP Setup / DHCP.
Supports 802.1x network access authentication.
Virtual Private Network (VPN): OpenVPN (requires third-party app support).
Virtual Local Area Network (VLAN).
Link Layer Discovery Protocol (LLDP)
Cisco Discovery Protocol (CDP)
Service Quality Assurance (QoS)
Primary Backup SIP Server
Relevant agreements
SIP2.0 over UDP/TCP/TLS, DNS A/SRV/NAPTR, RTP/RTCP/SRTP, STUN, DHCP, LLDP, CDP, 802.1x OpenVPN (requires third-party app support), SNTP, FTP/TFTP, HTTP/HTTPS, TR-069.
Physical Specifications:
Screen:7-inch (1024x600) color screen, IPS capacitive touch screen.
Keyboard:5 buttons, including:
1 Home Key
1 Return Key
2 voice control keys, increase/decrease
1 Hands-Free Button
RJ9 Connector: 2 pieces.
RJ45 Interface: 2 pieces.
USB 2.0 Interface:1, USB drive connection.
HDMI interface:1 piece
TF card slot:1 piece
Technical Specifications:
Power Supply: PoE
Power Consumption (PoE)3.11~ 10.76W
DC Input:5V/2A (Power adapter required, sold separately)
Power Consumption (Power Adapter): 2.38~8.4W
Operating Temperature: 0~45℃
Relative Humidity:10~95%
Installation Method:Desk-top or wall-mounted
Color:Black
Product Dimensions
Desk-top (Angle 1): 254.8x154.9x202.8mm
Desk-top model (Angle 2): 254.8x167.8x182.4mm
Wall-mounted: 254.8x118.4x206.9mm
Packaging Dimensions: 290x260x73mm
