Key Features:
Equipped with 2.4-inch 320240 Color Display, offering a comfortable visual and operational experience.
High-definition voice, supporting wideband audio decoding G.722 and Opus, with echo cancellation and noise reduction capabilities.
Supports a 6-party local conference function, enabling efficient coordination and office work within the enterprise.
Supports external EHS wireless headphones, allowing you to answer calls while handling other tasks.
100 Mbps Ethernet - Adaptive 10/100 Mbps network port, offering high-speed data transfer, with PoE power supply support.
Two installation options: desk placement or wall mounting, suitable for various application scenarios.
Automated deployment and configuration through FTP/TFTP/HTTP/HTTPS/DHCP OPT66/SIP PnP/TR-069.
Web Management Interface.
Local Telephone Directory (1,000 entries).
Web Phonebook (supports XML/LDAP, up to 1,000 entries).
Call Logs (Missed Calls/Incoming Calls/Outgoing Calls, 600 Entries).
Block Call List/Allow Call List.
Screen Saver on Standby.
Voice Mail Waiting Indicator (VMWI).
User-defined DSS key/soft key.
Network Time Synchronization
Support Plantronics wireless headsets/Jabra wireless headsets.
Supports recording (server-side recording).
Action URL/Active URI。
uaCSTA。
Call Function
Dialing/Answering/Rejecting Calls, Mute/Unmute (Microphone), Call Hold/Resume, Call Waiting, Intercom Function, Call Display, Speed Dial, Anonymous Call, Call Forwarding (Unconditional/Busy/No Answer), Call Transfer (In/Out of Office), Call Park/Grab (Server Supported), Redial, Do Not Disturb, Auto-Answer, Voice Mail (Server Supported), 6-Way Conference, Hotline, Shared Phone (Hot Desking).
Audio Features
Broadband ADC/DAC 16kHz Sampling
Narrowband Encoding: G.711a/u, G.723.1, G.726, G.729A/B, iLBC
Broadband Coding: G.722, Opus 1 full-duplex hands-free calling, supports acoustic echo cancellation (AEC)
Voice Activity Detection (VAD) / Comfortable Noise Generation (CNG) / Background Noise Estimation (BNE) / Noise Reduction (NR) / Automatic Gain Control (AGC)
Packet Loss Compensationncealment )
Dynamic Adaptive Jitter Cache
DTMF: In-band, Out-of-band (RFC2833/SIP INFO)
VQM Voice Quality Monitoring
Network characteristics
10/100 Mbps Ethernet.
IP Mode: IPv4/IPv6.
IP Acquisition Methods: Static IP Setup / DHCP / PPPoE.
Supports 802.1x network access authentication.
Virtual Private Network (VPN): L2TP / OpenVPN.
Virtual Local Area Network (VLAN)
Link Layer Discovery Protocol (LLDP)
Service Quality Assurance (QoS)
RTCP-XR (RFC3611), VQ-RTCPXR (RFC6035)。
Relevant agreements
SIP2.0 over UDP/TCP/TLS、RTP/RTCP/SRTP、STUN、DHCP、IPv6、LLDP、PPPoE、802.1x L2TP、OpenVPN、SNTP、FTP/TFTP、HTTP/HTTPS、TR-069、AES128 & AES256。
Physical Specifications:
Home Screen:2.4 Inches (320)240) Color Screen.
Keyboard:36 keys, including 4 dynamic software-defined keys (Soft-Key), 9 function keys (Hold, Transfer, Voice Mail, Address Book, Conference, Status, Headset, Redial, Hands-Free), 3 line keys (with LED indicators), 4 directional keys, 1 OK key, 12 standard phone number keys, and 3 volume control keys (increase/decrease/mute, microphone).
RJ9 Connector2 pieces.
RJ45 interface2 pieces.
Technical Specifications:
Power Supply: PoE
Power Consumption (PoE) 1.32 ~2.09W
Operating Temperature: 0~45℃
Relative Humidity: 10~95%
Installation Method:Desk-top or wall-mounted (wall mounting accessories required and sold separately)
Weight:8.55 kg
Product Dimensions:169x203.6x172.7 mm (Desktop, 45°)
Packaging Size: 250x220x55mm
