Duwan WDS40-160(I) Horizontal Centrifugal Pump

Horizontal Centrifugal Pump Manufacturer

Vertical pipeline pump

Motor power: 3 kW

Flow Rate: 12.5 Cubic Meters

Flow rate: 32 meters

2900 RPM

WDSHorizontal Single-StageThe centrifugal pump supply range includes complete sets. A complete set comprises: centrifugal pump and its driving motor; common base and foot bolts, nuts, and washers; coupling.(Or else)Fireproof shield; Mechanical seal; Cooling water/Insulating Mixing Hot Water System(As needed) Bearings lubrication unit; shaft vibration, shaft displacement, and bearing temperature monitoring probes(As needed)Pressure, temperature, and level display and monitoring electrical instruments for primary elements and secondary signaling elements of all systems(As needed)All internal wiring cables, junction boxes or terminal boxes, conduit pipes, supports and mounting brackets, as well as their fasteners within the base range; all connecting piping, pipe fittings, valves, flange joints, etc.; blind flanges, bolts, nuts, and washers for transportation; lifting ring set screws and/Or hanging ears; anti-static floor mat and/Or grounding rods; other necessary auxiliary equipment for operations; installation, trial run andOneAnnual operational spare parts; special tools, etc. The electrical and instrument equipment supplied should comply with the hazardous and explosion-proof levels of the applicable region. It should be ensured that no additional parts are required for the installation and safe, reliable operation of the goods.

Design and Installation Conditions

WDSHorizontalCentrifugalPipeThe pump is installed outdoors, with meteorological and environmental conditions referring to those of Lianyungang City.Rainproof requirementsDust-proof requirements, protection classIP65。

CentrifugalTechnical Specifications

The centrifugal pumps and their auxiliary equipment used in this project shall meet the requirements of the following standards:

ANSI/ASME B73.1-2001 Horizontal End Suction Centrifugal Pumps Technical Specifications for Chemical Industry

ANSI/ASME B73.2-2003 Vertical Centrifugal Pump Technical Specifications for Chemical Industry

ISO9905 Centrifugal Pump Technical Specifications—ⅠGrade (equivalent to)GB/T16907-1997）

GB/T5656-2008 Centrifugal Pump Technical Specifications(ⅡCategory)

GB/T5657-1995 Centrifugal Pump Technical Conditions(ⅢCategory)

GB/T3214-2007 Methods for Measuring Pump Flow

GB/T3216-2005 Reversing Power Pump Hydraulic Performance Acceptance Test1Grade and2Grade

JB/T8097-1999 Vibration Measurement and Evaluation Methods for Pumps

JB/T8098-1999 Method for Measurement and Evaluation of Pump Noise

Jiangsu Du'an Environmental ProtectionWDSHorizontalCentrifugal PumpMeets on-site working conditions and usage requirements

DuwanWDSSingle-stage horizontal centrifugal pumpFlow Rate and HeadPower specifications are detailed in the electronic sample.

The providedDuwan Single-stage CentrifugalThe pump should be: safe, reliable, practical, and economical, meeting the needs of the equipment for safe, stable, long-term, and full-load operation.

The providedBlue DeepWDSSingle-stage centrifugalPump Performance CurvePlease provide the Chinese content to be translated into American English.Pumps near their rated operating point and as close to maximumQ～H Scope is quite broad.WorkEfficiency.

WDSHorizontal Centrifugal PipePumpNo Chinese content provided.Piping and other equipment must not cause cavitation or overloading when operating together. The pump unit can work continuously for extended periods near the specified flow and head operating points.

CentrifugalAt shutdown, the pump impeller and other components should be undamaged before the check valve closes. Vibration reduction measures for the unit should be considered to minimize vibrations and noise during operation and during startup and shutdown of the unit and the piping system.

WDSHorizontal Centrifugal PumpFlow continuously rising to the shutdown point-Suction head curve, the suction head rise from the rated point to the shut-off point should be at least equal to the rated suction head.5%For pumps operating in parallel, the head increase from the rated point to the shut-off point should be at least equal to the rated head.10%。

Horizontal CentrifugalThe shutdown head of the pump should be less than or equal to the rated head.120%。

Under the rated impeller, to ensure high efficiency and low vibration during operation, the pump's operating point should ideally be located at:GoodScope of WorkNormalEfficiency point traffic70%~120%The normal operating point flow of the pump should not exceedGoodEfficiency point flow, keep the normal operating point as close as possibleGoodEfficiency points, and try to stay as far away as possible.Please provide the Chinese content you would like translated into American English.Low flow point.

WDSSingle-stage horizontal centrifugePump performance, including efficiency, flow rate, head, power consumption, and necessary NPSH (Net Positive Suction Head) requirements, are allMeet the field operating conditions requirements.
