Features and Benefits

The handle shell is made of special PC glass fiber reinforced engineering plastic.

2. Integrated structure with excellent sealing, waterproof up to IP67 rating, and a compact internal layout. Explosion-proof strength reaches IK09.

3. The handle features a mechanical switch button for controlling the call.

4. Equipped with puncture-resistant, high-fidelity, and waterproof transmitters, ensuring the communication transmission characteristics of the compatible phones. The transmitter features an impedance of 150 ohms with dynamic noise suppression, while the receiver is a high-fidelity type with an impedance of 1000 ohms, complying with the requirements of GB/T15279-2002, Section 4.2.

5. The standard handle end interface is an Amphenol AP-125 (U-128/U) type 5-pin aviation connector, compatible with AN/PRC-70 and AN/PRC-77 radio communication equipment. Different interface types and connector models can be customized according to customer requirements.

Packaging Details

Outer Carton Dimensions: 430*390*380mm

25PCS/CTN

12.5Kg/CTN

User Selection

Standard configurations are available for any handle design, but modifications can also be made as follows:

Handle color can be customized according to customer requirements.

2. Spring wire length can be customized to meet customer requirements.

3. Wiring principles and connectors can be modified according to customer requirements.

After-sales service

In the absence of human damage, our company is responsible for free repairs within 1 year.
