Ultrafiltration membrane separation technology is the core component of ultrafiltration equipment, primarily used to separate microparticles, colloids, and high-molecular organic substances from solutions.UltraFilter membranes, which are characterized by uniform pore sizes, with a rated pore size range of0.01Micron-sized microporous filtration membranes. Applying appropriate pressure to one side of the membrane can sieve out solute molecules smaller than the pore size, thereby separating molecules with a molecular weight greater than...500Dalton(Atomic Mass Unit)Particle size greater than10Nanometer-sized particles. Ultrafiltration membranes are among the earliest developed high molecular separation membranes, in60The ultrafiltration devices have been industrialized since the era. Depending on the membrane material used, ultrafiltration can be categorized into microporous filtration and molecular weight cut-off filtration.
Microfiltration: Represented by polysulfone.
Over molecular weight filtration: Represented by hollow fiber.
Methods and Steps:
The ultrafiltration membrane screening process utilizes the pressure difference between the two sides of the membrane as the driving force. With the ultrafiltration membrane as the filtration medium, under certain pressure, when the feed solution flows over the membrane surface, only water and small molecule substances can pass through the densely packed numerous tiny micropores on the membrane surface to become the permeate. The industrial application of ultrafiltration membranes is very extensive and has become one of the new types of chemical unit operations. They are used for separating, concentrating, and purifying biological products and in the food industry.
Process Flow:
1Raw water→Original Water Tank→Multi-media Filter (Quartz Sand)→Activated Carbon Filters (fruit shell activated carbon, compressed activated carbon, etc.)→Softener
2First-grade reverse osmosis unit →Intermediate Water Tank→Intermediate pump→Second-level reverse osmosis system
3Pure water production to purification tank
4Pure Water Tank→Pure Water Pump→Ultraviolet Sterilizer
5Water Storage Drum
Principle of ultrafiltration equipment:
Ultrafiltration is a membrane separation process that uses sieving as the separation principle and pressure as the driving force, with a filtration accuracy of0.005-0.01μmWithin the scope. Effectively removes microparticles, colloids, bacteria, heat sources, and high-molecular organic substances from water. For ultrafiltration equipment procurement, turn to Jiangsu Pume Environmental Protection Technology Co., Ltd. Widely applicable in the separation, concentration, and purification of substances. The ultrafiltration process has no phase transition, operates at room temperature, is particularly suitable for the separation of heat-sensitive substances, and possesses excellent temperature resistance, acid-base resistance, and oxidation resistance. It can60℃ Below,pHPlease provide the Chinese content to be translated.2-11Subject to the specified conditions, for long-term and continuous use.
Applications of Ultrafiltration Equipment:
Beverages, juices, dairy products, wines, soy sauce and vinegar, etc., purification treatment for industrial water Seafood Processing and Preservation
Fish Meal Shrimp Crab Sticks De-salination and refining of food products such as squid strings.
Water for Soft Can Food Production, Soft Packaged Beverage Juice Concentrate Plant Protein Beverage WaitWater treatment.
