Raw water flows under pressure on the outside or inside of the hollow fiber, forming external pressure and internal pressure configurations respectively. Ultrafiltration is a dynamic filtration process where retained substances can be removed with the concentrated water, preventing clogging of the membrane surface, allowing for long-term continuous operation. Ultrafiltration membranes are among the earliest developed high polymer separation membranes. Ultrafiltration technology is widely used in water purification, solution separation and concentration, as well as the extraction of useful substances from wastewater, and the purification and reuse of wastewater. New technology features include simple operation, no need for heating, energy conservation, low-pressure operation, and a small footprint of the installation.

Features:

1.The ultrafiltration process is conducted at ambient temperature, with mild conditions and no component damage, making it particularly suitable for separating, grading, concentrating, and enriching heat-sensitive substances such as drugs, enzymes, and juices.

2.The ultrafiltration process does not involve phase changes, requires no heating, has low energy consumption, does not necessitate the addition of chemical reagents, and is non-polluting, making it an energy-saving and environmentally friendly separation technology.

3.High-efficiency ultrafiltration technology is highly effective for the recovery of trace components in dilute solutions and concentration of low-concentration solutions.

4.The ultrafiltration process solely utilizes pressure as the driving force for membrane separation, thus making the separation unit simple, with a short process, easy to operate, and convenient for control and maintenance.

Features:

1.Stainless steel clamp structure, with enhanced pressure-bearing capacity, effectively prevents bursting and leakage due to the sudden high pressure and impact in medium-scale ultrafiltration systems.

2.The housing is made of high-tensile material.UPVCMaterial, this material exhibits excellent anti-aging properties..Features of resistance to acids, alkalis and chemical stability, suitable for a wide range of operating conditions.

3.Utilizing a unique7Sectoral winding technology ensures even water distribution within the shell.

4.Filling Film Filament5000Root16Effective membrane area per square meter is significantly higher than that of similar products, resulting in a greater water flux per module.

5.Inlets and outlets are all in compliance with national standards.DN32The interfaces, with four live-threaded end caps, are all uniform in size for easy installation and maintenance.

6.Effective membrane area large, high water flux, pure water flux3500Increased, significantly higher than domestically produced products of the same specification  。

System Features:

1.The separation process does not involve phase changes, and it can be conducted at room temperature, making it suitable for concentrating or purifying heat-sensitive substances such as juices and biological preparations.;

2.The equipment occupies a small footprint, is easy for modular design, and has strong expandability.;

3.The separation process is driven solely by low pressure, consuming less energy.;

4.Equipment and process flow are simple, easy to operate, manage, and maintain.;

Application Fields:

1.Municipal, power, steel, petrochemical, textile, food, and other fields: advanced wastewater treatment for reuse and process water treatment;

2.Municipal water purification treatment;

3.Desalination and Pretreatment for Reverse Osmosis Systems;

4.Food and biochemical industries - purification, concentration, and separation.
