Key Technical Specifications
1. Input:
① Flow Signal Input: (Two-wire System Signal) Magnetic Switch (Elliptical Gear Flow Meter)
2. Output Signal:
a) Fixed-value output: 24V, 0.1A. (Compatible with DC24V universal relay, for controlling pumps or valves).
b) Output Quantity: 24V, 0.1A. (Compatible with DC24V general-purpose relays, for controlling pumps or valves).
c) Synchronous pulse signal output: OL ≤ 1V, OH > 10V
d) Displacement Data Signal Output: Compatible with on-site high-definition screen data display units for synchronized display of actual quantities, clear and intuitive. (Optional; purchase on-site high-definition screen data display units as needed,)
e) Communication Output: RS-485 Serial Communication Port (compatible with long-distance communication modules)
3. Maximum cumulative total: 99,999 (liters or kilograms).
4. Quantitative Range: 0.1L - 999.9L
5. Accumulated Error: ±1 Pulse
6. Interval Time: 1-999s, Batch: 1-999 batches
7. Power Supply: 220V ±10%
8. Standard RS-232 communication method is used for reliable transmission. Equipped with a communication transmitter, the communication distance can reach up to 1,200 meters.
