Product Technical Specifications

1. Electrical specifications

(1) Standard power of constant power electric heating tape: 40w/m

(2) Rated Voltage: 220V

(3) Maximum heating length: 100-130m

(4) Temperature Controller Must Be Provided

(5) Equipped with a leakage protection device

2. Thermal performance specifications

At -10°C ambient temperature and 10 m/s wind speed, the internal temperature of the pipe can be maintained between 40-160°C.

(2) Sampling tubes are resistant to corrosion from various acidic and alkaline mediums, with a pressure resistance of 0.6 Mpa and no leakage.

(3) Sampling tubes can operate continuously at temperatures up to <250 degrees Celsius.

3. Installation Specifications

(1) Composite pipe minimum bend radius: 0.5m

(2) Maximum continuous length: 100-130m

(3) Limited fixed distance: 5m vertically, 2m horizontally

Note: Do not twist or drag on the ground during installation; the pipe end sleeve is only to be removed during the installation of the connection point.
