Application Range: Building, cold storage, and warehouse floor heating; inclined ramp heating and roof defrosting.

Features

Good thermal resistance. The entire product uses silicone rubber as an insulating thermal material (including power cables), with operating temperatures ranging from -60 to ±200°C.

(2) Excellent thermal conductivity: Heat can be generated immediately, directly conducting heat with high efficiency, and can achieve the effect with short-term heating.

(3) Reliable electrical performance: Each electric heating tape is tested rigorously for direct current resistance, immersion high-voltage, and insulation resistance before shipment to ensure quality.

(4) Robust construction with ease of bending flexibility; integrates with the overall cold tail end without any joints. Reasonable design for easy installation.

(5) Highly customizable; heating length, wire length, rated voltage, and power are determined by the customer.

Product Structure

1- Heat-resistant wire is composed of two tin-coated copper wires with a cross-sectional area of 0.75 mm².

The isolation layer is manufactured using the extrusion method for silicone rubber.

A high-strength alloy wire helix, in contact with the silicone rubber surface, forms the heat-generating core.

4- Sealed Coating Made by Extrusion Method

Product Specifications

Voltage 36V-240V, determined by the user.

(1) 25W/m, withstands AC 3500V, with a long limit of 65 meters.

(2) 40W/m, withstands AC 3500V, with a maximum length of 50 meters.

(3) 50W/m, withstands AC 3500V, with a long limit of 44 meters.

Technical Specifications
