Application Environment
◆Ambient Temperature: Indoor Type -15℃~60℃, special models available from -30℃~+60℃
Altitude: 2,000m, with special conditions reaching up to 4,000m.
◆Operating Environment: No explosive mixtures containing dust, gas, smoke, etc. are allowed.
Key Features
Standard Features
◆ Optional Features
The participation replaces the original PT cabinet function.
Harmonic Suppression Function
Overvoltage protection function
Selection Function
Arc Suppression Function
◆ Features
(1) Utilizing a 32-bit processor based on the ARMv7TDMI-S core from PHILIPS, the data collection and analysis are carried out using multi-core technology. With clear division of labor among units, the collection speed is significantly improved.
Judgment is more accurate;
(2) In the event of single-phase arc grounding in the system, it can be quickly converted to metallic grounding.
(3) The device promptly alarms when the system generates a metallic grounding or PT open circuit.
(4) Conduct cyclic testing on the PT opening triangle voltage, real-time data collection, and analysis and calculation of the data through digital measurement, filtering, amplification, and other digital signal processing techniques.
If a fault occurs, identify the current fault type; if it is ferromagnetic resonance, instantly activate the detuning circuit to eliminate 17Hz (1/3 octave), 25Hz (1/2 octave), 50Hz (power frequency), and 150Hz (3rd harmonic).
Ferromagnetic resonance at frequencies of 100 kHz and above
(5) Available for automatic or manual switching;
(6) This device features an accident recall function, capable of recording the time and action status of up to 30 events.
