TELEC Certification Overview
《The Radio Law mandates type approval for radio equipment.(That is, Conformity Assessment of Technical Regulations). Certification is mandatory, with MIC as the certifying body, registered as an authorized certification body within the scope of radio equipment. TELEC (Telecom Engineerina Center) is the primary registered certification body for compliance certification of radio equipment in Japan. The technical standards for the wireless TELEC certification are detailed in the classification of radio equipment and technical standards listed in the Technical Regulations Conformity Assessment System on their website. It should be noted that in cases where these technical standards differ from the technical requirements of the "Radio Regulations" (Radio Regulatory Commission Rules No. 18), the "Radio Regulations" shall prevail.
Wireless radio frequency products include:：
Bluetooth ProductsZigBee products, remote sensors, WiFi products, wireless microphones, pagers, LTE·RFID (2.4GHz, 920MHz) products, UWB radio systems, GSM products, etc.
TELEC Certification Type
TELEC certification includes Test Certification and Type Certification
Certification(Tvpe Certification). The test certification is for each
Each device unit is verified; this certification is valid only for each individually verified unit.
Equipment Unit EffectiveFormal type approval refers to the certification of a batch of equipment with the same design and manufacture.
The samples provided are being verified; this certification is valid for this batch of equipment, but if...
If the design or manufacturing of the equipment has changed, the equipment will require re-certification.
TELEC Certification Process
1. Sign a certification contract with the company and pay the certification fee.
2. Provide one fixed-frequency model and one standard model, along with the application form and certification documents.
3. The company begins testing and issues a test report, submitting it to the RCB agency for application.
4. Upon completion of the review, issue the certificate, pay the final balance, and the company will send out the certificate, marking the case closed.
TELEC Certification Documents
1. System Block Diagram
2. Complete Machine Block Diagram (System Schematic)
3. User Manual
4. Operation Instructionscription）；
5. Bill of Materials (BOM)
6. Module Schematic
7. Module Block Diagram
8. Module Specification Sheet
9. Manufacturer's ISO9001 Certificate (ISO9001 certificate of manufacturer)
10. Label and location drawings (label location label sample drawing photos)
11. Antenna Specification Sheet: Includes antenna name and antenna type
12. Label: Must indicate size and location diagram on the product, must display the TELEC logo, and specify the size of the TELEC logo.
The above information is only accepted in English or Japanese test reports; the same applies. Please note that when submitting, the number of models should be considered, as a high number may necessitate product differentiation testing or the submission of model review fees. Under the Japanese Radio Law, manufacturers are obligated to retain certification documents.10 years.
