TELEC Certification Overview
《The Radio Law mandates type approval for radio equipment (i.e., compliance with technical regulations). Certification is mandatory, and the certifying body is MIC, a registered certification body recognized within the scope of radio equipment. TELEC (Telecom Engineerina Center) is the primary registered certification body for radio equipment compliance certification in Japan. Technical standards for the wireless TELEC certification are detailed in the Radio Equipment Classification and Technical Standards listed under the Technical Regulations Compliance Certification System on their website. It is noteworthy that in cases where these technical standards differ from the technical requirements of the Radio Regulations (Radio Regulatory Commission Rules No.18), the Radio Regulations take precedence.
Wireless radio frequency products include:：
Bluetooth products, ZigBee products, Telemetry devices, WiFi products, Wireless microphones, Pager, LTE·RFID (2.4GHz, 920MHz) products, UWB radio systems, GSM products, etc.
TELEC Certification Type
TELEC Certification includes Test Certification (TestCertification) and Type Certification
Certification (TvpeCertification). Test certification is for each
Each device unit is verified; this certification applies only to each unit that has been validated.
Unit equipment is effective; Type certification refers to the certification of a batch of equipment with the same design and manufacture.
Verify the samples prepared, this certification is valid for this batch of equipment, but if...
If the design or manufacturing of the equipment has changed, the equipment will require re-certification.
TELEC Certification Process
1. Sign a certification contract with the company and pay the certification fee.
2. Provide one each of a fixed-frequency model and a standard model, along with the application form and certification documents.
3. The company begins testing and issues a test report, submitting an application to the RCB agency.
4. Upon completion of the review, issue the certificate, settle the final payment, and the company will mail out the certificate, case closed.
TELEC Certification Documents
1. System Block Diagram
2. System Block Diagram
3. User Manual
4. Operation Instructionscription）；
5. Bill of Materials (BOM)
6. Module Schematic
7. Module Block Diagram
8. Module Specification Sheet
9. Factory ISO9001 Certificate (ISO9001 certificate of manufacturer)
10. Label and location diagrams (label location label sample drawing photos)
11. Antenna Specification Sheet: Includes antenna name and antenna type
12. Label: Must include size and placement diagram on the product, display the TELEC logo, and specify the size of the TELEC logo.
The above information is only accepted in English or Japanese. Test reports in other languages are not accepted. Additionally, when submitting, please pay attention to the number of models; a large number may require product differentiation testing or submission of model audit fees. Under the Japanese Radio Law, manufacturers are obligated to retain certification documents for 10 years.
Wireless chargers and wireless speakers are both wireless products that require TELEC certification, also known as MIC certification, for export to Japan.
