Blow molding film processing wholesale generally follows this process flow:

Hopper feeding → plasticizing extrusion → blow molding and stretching → wind ring cooling → V-shaped clamp → pull roller traction → corona treatment → film winding

However, it is worth noting that the performance of blow molding processed wholesale film is greatly related to the production process parameters. Therefore, during the blowing process, it is essential to strengthen the control of process parameters, standardize process operations, and ensure the smooth progress of production to obtain high-quality film products. In the production of polyethylene blow molding processed wholesale film, the main focus is on controlling the following process parameters:

Extruder temperature

During blow molding of low-density polyethylene (LDPE) film, the extrusion temperature is typically maintained between 160℃ and 170℃, with the requirement for uniform die head temperature. Excessive extrusion temperature can lead to resin decomposition and脆f film, particularly causing a significant drop in longitudinal tensile strength; conversely, too low a temperature results in poor resin plasticization, preventing smooth expansion and stretching, resulting in lower film tensile strength, poor surface luster and transparency, and even the appearance of wood grain patterns and unmelted crystal nuclei (fish eyes).

2. Blowing Ratio

Blow-up ratio is one of the key control points in the blow molding process for wholesale film production, referring to the ratio between the diameter of the blown film bubble and the diameter of the unblown tube ring. The blow-up ratio represents the lateral expansion multiple of the film, which is essentially a lateral stretch of the film. This stretch exerts a certain degree of orientation on the plastic molecules, with an increased blow-up ratio enhancing the film's lateral strength. However, the blow-up ratio should not be too high, as it can lead to unstable bubbles and frequent creases in the film. Therefore, it should be properly coordinated with the draw ratio. Generally, the blow-up ratio for low-density polyethylene (LDPE) film should be controlled between 2.5 and 3.0.

Blow molding wholesale products generate pollutants.

During the blow molding processing and wholesale manufacturing, plastic granules volatilize at high temperatures, producing a small amount of organic waste gas, primarily consisting of non-methane total hydrocarbons.
