Bull 60kW Truck Electric Vehicle Universal 380V DC Charging StationElectric Bus Charging Pile - The DC charging pile for electric buses has a higher power rating, offering...100~200kWOn the left, a total input line loop is configured with an electric power quality analyzer to monitor the power quality of the entire charging station power supply loop. Meanwhile, an electrical fire monitoring device is set up. The charging loop uses three-phase power supply, with the input line utilizing an AC plastic case circuit breaker. The three-phase main loop is equipped with a residual current relay to provide protection against indirect contact electric shocks. Due to the high power consumption of such charging stations, it is recommended to install a track-type electric power meter in the three-phase AC loop for total power measurement, complemented by a DC electric power meter to monitor the overall operational efficiency of the charging station. The charging management controller is responsible for the external human-machine interface, charging control, reading the DC electric power meter's data, and controlling the opening and closing of the DC charging output circuit breaker.

Bull 60kW Truck New Energy Electric Vehicle Universal 380V DC Charging StationElectric Vehicle Charging StationManagement SystemPrimary Functions Resource Management Charge Station File Management, Charging Pole File Management, User File Management, Charging Pole Operation Monitoring, Abnormal Transaction Monitoring for Charging Poles (II) Transaction Settlement Charging Pricing Strategy Management, Prepayment Management, Billing Management, Revenue and Financial Reporting (3) User Management User Registration, User Login, User Account Management, Message Management (4) Charging Services Charge Facilities Search, View Charge Facilities, Map Addressing, Online Self-service Payment for Charging, Charging Settlement, Navigation, etc. (V) Mini Program on WeChat Scan-to-charge, bill payment, and other features Data Services Data collection, SMS alerts, data storage, and analysis Transformer Charging station transformer load, scheduling and management for the charging桩 during overload
