Bull Desktop Column 11KW Residential & Commercial New Energy Vehicle Charging StationElectric Bus Charging Poles - The DC charging桩 for electric buses has a higher power rating, suitable for...100~200kWOn both sides, a total input line loop is configured with an electric power quality analyzer to monitor the power quality of the entire charging station supply loop. Simultaneously, an electrical fire monitoring device is set up. The charging loop uses three-phase power supply, with the input line using an AC plastic case circuit breaker. The three-phase main loop is equipped with a residual current relay, providing electric shock protection for indirect contact. Due to the high power consumption of such charging stations, it is recommended to configure a track-type electric power meter in the three-phase AC loop for total energy measurement, complemented by a DC electric power meter to monitor the overall operational efficiency of the charging station. The charging management controller is responsible for the external human-machine interface, charging control, reading the DC electric power meter's energy data, and controlling the opening and closing of the DC charging output circuit breaker.

Bull Tower 11KW Residential & Commercial Electric Vehicle Charging Station for New Energy VehiclesElectric Charging StationManagement SystemPrimary Functions Resource Management Charging Station Record Management, Charging Pole Record Management, User Record Management, Charging Pole Operation Monitoring, Charging Pole Anomaly Transaction Monitoring (II) Transaction Settlement Charging Price Strategy Management, Prepayment Management, Billing Management, Revenue and Financial Reporting (3) User Management User Registration, User Login, User Account Management, Message Management (4) Charging Services Charge facility search, view charge facilities, map addressing, online self-service charging payment, charging settlement, navigation, etc. (W) Mini Program on WeChat Scan-to-charge and bill payment features (Six) Data Services Data collection, SMS alerts, data storage and analysis Transformer Charging station transformer load, scheduling and management of charging stations during overload
