Operating Principle:
Closed-loop cooling towers are a heat exchange device developed and improved upon the heat exchange technologies from both domestic and international sources.
Principle Diagram:
Product Features
High heat exchange performance
The GWBS products utilize the technology of a coil with a feng shui directional cross-flow type secondary heat exchange combined with PVC filling, achieving heat exchange.
Due to the airflow and spray water flowing in the same direction through the coil, the spray water covers the coil surface evenly, keeping it moist. Compared to the reverse airflow and water spray structure, it reduces the formation of dry spots on the coil wall and scale.
Low operation cost, energy-efficient and environmentally friendly
Due to the structural design of the product and its high thermal performance, it boasts low condensation temperature, energy and water savings, low noise, environmental friendliness, and low maintenance costs.
Continuous operation with maintenance shutdown
The GWBS products can be serviced on-site without shutting down, for float ball valves and filter screens. Due to the same-direction design structure of water and air, it is convenient to inspect nozzles and coils while the equipment is running.
Easy maintenance
Equipped with a user-friendly structural design, featuring a service door, the interior space is spacious, allowing maintenance personnel to conveniently perform inspections within the product.
Easy-to-clean sloped sump pit
A design with a sloping structure from the bottom of the sedimentation pond towards the effluent outlet, facilitating the drainage of wastewater and settled impurities.
Low land area, low comprehensive investment
The GWBS product line integrates traditional condensers, cooling towers, circulating pumps, water basins, and connecting pipes into one unit, allowing for normal operation without the need for additional equipment. It boasts advantages such as minimal land occupation and low overall investment.
Direct-drive fan
The fan features a direct-drive structure, eliminating transmission loss associated with belt drive mechanisms. It is low-noise and has a low failure rate.
Easy transportation and installation
GWBS products are shipped using standard upper and lower box components for easy transport and installation on-site.
Condenser Tube Bundle
The condenser coils are made of φ25mm (GB/T8163) seamless fluid pipes, with a design pressure of 1.97MPa. The coils are焊接, assembled, and then subjected to a 2.5MPa airtightness test (three times) in water after overall hot-dip galvanizing. The overall hot-dip galvanizing treatment of the condenser coil assembly enhances the corrosion resistance and extends the service life. The coils are inclined along the refrigerant flow for easy liquid discharge, and they feature a low pressure drop.
Configure electronic water descaling unit
Equipped with an electronic scale inhibitor, which utilizes electronic pulse technology to prevent and remove scale from circulating water, as well as to treat algae.
Recirculating pump
Recirculation pumps feature mechanical seals without directional limitations, ensuring no leakage and a long service life. They are equipped with outdoor-type motors, featuring imported bearings for long-term, reliable operation of the pump unit. These pumps are characterized by low power consumption, high flow rates, and low noise.
Detachable Dehumidifier
The GWBS product's removable dehumidifier is made of corrosion-resistant PVC material, which, by altering the air flow direction, removes moisture from the wet air exiting the coil, reducing water drift to below 0.001. It is easy to remove the dehumidifier when cleaning the packing material.
