Material Specifications for Analysis Cabin:

The analysis cabin's frame, base, and roof are composed of metal components, welded from shaped steel, offering sufficient strength and rigidity. This ensures stability during loading, lifting, shifting, and transportation.Product type modular assembly structure，Exterior panels are made of stainless steel sheet.304SS, with brushed stainless steel foil.OrGalvanized steel sheet, when using galvanized steel sheet, surface painting treatment is required; the paint color should be white or international gray, and interior wall panels and ceilings are recommended to use1.5mm to 2.0mm stainless steel roof panels must have a waterproof design, which can be either a clip-type modular waterproof design or a flat welding waterproof design. Insulating materials with flame retardant properties (such as mineral wool) should be filled between the interior and exterior walls, as well as between the interior and exterior ceilings, with a thickness of 70 to 75mm (3in). In extremely cold or hot regions, the insulation should be thickened to 80 to 85mm. The floor is made of anti-slip metal plates, 4 to 6mm steel sheets. Materials can be textured stainless steel plates, textured galvanized steel plates, or hot-rolled steel plates, with surface coating required for galvanized or hot-rolled plates.
