Rated Voltage AC 24V, 50/60Hz, DC 24VRated voltage range AC 19.2-28.8V / DC 21.6-28.8V Power consumption 13W @ rated voltage / 1.5W @ holdTransformer capacity 23VA (MAX current 20A @ 5ms)Cable Connector, Cable Length 1m, 4x0.75mm²Torque: 8Nm @ rated voltageControl Signal Y DC (0)2 10V @ Input Resistance 100kΩPosition Feedback Signal U DC 2-10V @ MAX 0.5mAPositional Tolerance ±5%Rotation direction is selected via the switch for 0 or 1.Rotation direction selection button status: Y=0V, switch position 0 or 1Manually press the manual operation button to unlock the actuator gear mechanism, allowing for manual rotation of the wind shaft to an angle of MAX 95°, with mechanical adjustment available.Operation time: 4sAdjustable operating range and measurement signalAchieve operating angle positioningPress the "Adaptive" button to manually trigger the adaptive feature.

Noise Level MAX 52 dB(A)Position Indicator MechanismNegative torque ≤ 50% of rated torque (subject to conditions)Electrical shock protection class III (Safe Extra Low Voltage)Electrical Protection Rating IP54EMC CE complies with 2004/108/ECCertification in compliance with IEC/EN 60730-1 and IEC/EN 60730-2-14; operating environmental temperature -30 to +40°C (unrestricted)+40 to +50°C (with conditions)Non-operating temperature range -40 +80°CHumidity: 5 - 95% relative humidity, no condensation
