The Mingtong chillers come in two types: water-cooled and air-cooled. The working principle is the same: initially, the compressor吸入the low-temperature, low-pressure refrigerant gas after evaporation cooling, then compresses it into high-temperature, high-pressure gas and sends it to the condenser. The high-pressure, high-temperature gas is cooled in the condenser, condensing into a normal temperature, high-pressure liquid. As this liquid flows into the thermal expansion valve, it is throttled into low-temperature, low-pressure wet steam, which then flows into the evaporator. It absorbs the heat of the refrigerant water in the evaporator, lowering the water temperature. The refrigerant is then reabsorbed into the compressor, repeating the cooling cycle. The difference between air-cooled and water-cooled types is the heat dissipation method: air-cooled dissipates heat through finned condensers, which is then dispersed into the external air by a cooling fan. Water-cooled types require a cooling tower, transporting heat to shell-and-tube condensers, and circulating it through a pump to the cooling tower. Due to the high temperature and high pressure during compressor operation, in summer when the ambient temperature is relatively high, water-cooled types have better cooling effects, but require cooling water and an additional cooling tower. Air-cooled types are flexible for assembly and easy to install, suitable for areas with water scarcity or for mobile applications. Depending on regional environments, water quality, and production needs, we offer various models, including shell-and-tube, box-type with water tank and pump, titanium alloy, stainless steel, open type, screw type, evaporative type, split type, explosion-proof type, low-temperature type, and combined hot and cold type, all designed for different locations.

Features:

(1) We select original brand compressors such as Copeland (Gulley) from the U.S., CompAir from France, and Hanbell from Taiwan for medium and low-temperature compressors.

(2) Utilize refrigerants such as R404A, R410a, R22/R407C, and R22 to meet refrigeration temperature and environmental requirements.

(3) Temperature Range Selection: Offers process chilled water at temperatures from 25°C to -85°C (users can select different unit specifications based on varying production needs)

(4) Available in various refrigerants (cooling water) to meet customer requirements: ethylene glycol solution, alcohol, ternary mixture, calcium chloride, seawater, electroplating, electroosmosis, etc., with evaporators designed according to anti-corrosion specifications.

(5) Designed for 24/7 continuous operation, capable of meeting the cold source requirements for various continuous production processes.

(6) The unit also features an internal water tank and circulating pump for cooling capacity, eliminating the need for a cooling tower and cooling pump, making installation and maintenance simple and convenient.

(7) Equipped with various safety protection devices, offering stable performance, low noise, long service life, and easy operation; features a liquid crystal display human-machine interface (PLC option), ensuring simple and convenient operation with a clear overview of running conditions.

Mingtong Refrigeration Equipment Co., Ltd. is a comprehensive production enterprise specializing in research and development, manufacturing, sales, and service. Through technical collaborations with world-renowned compressor manufacturers and independent innovation, we continuously enhance product performance and uphold product quality. Relying on our professional technical team, scientific management system, and comprehensive after-sales service, we have earned the favor of numerous clients. Our products are widely used in industries such as rubber, plastics, oil, chemicals, electronics, papermaking, textiles, brewing, biology, food, machinery, beverages, vacuum coating, electroplating, and laboratories. Additionally, they are commonly applied in centralized cooling systems.
