Steel siloPressure Relief Valve

When abnormal pressure poses a threat toSteel storage siloIn structural design, the pressure safety valve is the last line of defense. That is when...Steel siloThe reason for immediate action during sudden excessive overpressure or over-depressurization inside. A highly efficient and reliable pressure safety valve is an indispensable piece of equipment for the steel silo system.

When the pressure value is within the preset range, the helical spring keeps the valve cover closed. The three external spring rods maintain a tight seal on the external annular valve cover until the pressure generated inside the steel storage tank is less than the spring force. WhenSteel siloWhen the internal pressure is too high or too low, once the pressure value exceeds the preset range, the valve cover is pushed up to release pressure. The smaller valve cover covers the central circular opening of the external valve cover from below. The smaller valve cover is fixed by a single spring rod and pressurized to the external valve cover by standard atmospheric pressure inside the steel plate storage. During the pressure extraction, the spring compresses and the valve cover drops. Air enters from the outside of the steel plate storage, ensuring quick pressure balance and pushing the central valve cover into the closed position. The entire process does not require manual operation. It is widely used at the top of storage cylinders and storage hoppers, typically accompanied bySteel storage siloDust removal equipment on the storage roof should be used in conjunction. The all-valve should be vertically installed and mounted at the gas phase interface of the steel silo or pipeline.
