1. Equipment Purpose:

This series of products is widely used in the sintering of products in vacuum or protective atmosphere for inorganic materials (such as ceramic seals, zirconia, zinc oxide, aluminum oxide, etc.), metal compounds, ceramics, and inorganic compounds. It is also suitable for the heat treatment of metals in vacuum or protective atmosphere for sintering preparation, as well as for the heat treatment of materials that require a clean sintering environment. Additionally, it is applicable for pilot batch production use in colleges and universities, and scientific research institutions.

II. Equipment Features:

2. The furnace is equipped with an inflation overpressure explosion-proof system.

3. The furnace is equipped with a temperature monitoring device, which monitors the furnace temperature in real-time, preventing overheating and damage to the furnace.

4. Full stainless steel design, ensures clean waterways that do not rust or scale, preventing clogs in the waterways.

5. Programmed temperature ramping, pre-set process temperature ramping, one-touch operation, with infrared temperature measurement

PLC and touch screen control method, high degree of automation

7. Furnace Pressure Explosion Protection Device, Prevents Overpressure Inside the Furnace

Section 3: Configuration Details:

1. Vacuum Configuration: Mechanical Pump System 5Pa; Mechanical Pump + Diffusion Pump System 5×10E-3Pa

2. Heating Power Configuration: 10-100KW, customizable design available

3. Workspace Configurations: 80*80, 120*120, 160*160, etc., up to 200*200; available for custom sizes.

4. Temperature Range: Standard 1000-2300°C, freely selectable.

Our company offers custom-made sintering furnaces for various tungsten, molybdenum, and graphite wires, with a diverse range of structural designs!
