ZA (Trapezoidal Threaded Rod Type)Screw jack with worm gear It is a fundamental lifting component featuring compact structure, small size, light weight, wide power sources, noiseless operation, easy installation, flexible use, multiple functions, various matching forms, high reliability, and long service life.，Broadly used in industries such as machinery, metallurgy, construction, and hydraulic equipment, featuring multiple functions including lifting, lowering, as well as advancement, rotation, and adjustment to various height positions with accessories.Can be used individually or in combination, capable of accurately controlling and adjusting the lifting or propulsion height according to a certain program, and can be powered by an electric motor or other power source.。It comes in various structural and assembly configurations, and the lifting height can be customized according to the customer's requirements.。

ZATrunnion type (trapezoidal screw type) is suitable for low-speed and low-frequency applications., The main components include: precision trapezoidal screw and high-precision worm gear sets.Economy:Compact structure, easy operation, convenient maintenance；Low speed, low frequency: Mainly used in high-load, low-speed applications that do not require frequent operation.；Maintain Load: The trapezoidal screw features an automatic locking function, enabling load maintenance even without a braking device. Note:In case of significant vibration or impact loads, the self-locking function may fail. Please add an external braking device at this time.

ZAScrew jackFeatures:

◆Unique modular design;

◆ Eco-friendly appearance structure design with independent intellectual property rights.

◆ Gear wheels are precision-machined with German-imported worm gears.

◆Thread surface hardening treatment, surface hardness reaches500-550HV；

Low friction, long lifespan.

◆ Widely applicable power source, can be directly driven by motors or other power sources, or operated manually.

◆Diverse output types

NM Screw JackThis lifting screw is powered by worm gear transmission to perform functions such as lifting, lowering, advancing, and flipping. It is a fundamental lifting component widely used in various industries including machinery, metallurgy, water conservancy, chemical, cultural, and healthcare. It boasts compact structure, small size, light weight, easy installation, flexible operation, high reliability, excellent stability, and long service life. It can be directly driven by an electric motor or other power sources, or manually. This series of worm screw lifting machines features self-locking capabilities and high load-bearing capacity.2.5t to 120t capacity, input speed of 1500 rpm, hoisting speed of 2.7 m/min, available in various structural types and assembly methods. Operating temperature range: -20 to 100°C. Hoisting height customizable to customer requirements.

Features of screw jack:

1. Smooth transmission, noise-free.

2. Low impact vibration

3. Suitable for low-speed, high and low frequency applications.

4. Primarily for medium to small loads.

5. Maintain Load Capacity: The trapezoidal screw features an automatic locking function, which can maintain the load even without a braking device.

6. Safety Setting: To prevent exceeding the travel distance and damage to the screw and nut, a travel switch is specially configured.

The screw jack system components include: screw jacks, reducers, motors, reversing switches, drive shafts, couplings, brakes, clutches, etc. As long as the customer provides specific technical requirements, Engineers will provide detailed calculation procedures, system component selection, andCAD assembly drawing. Our technical support will be professional. A mature and reliable technical solution will ensure the safety of your equipment.

NM screw jacks can be used as a single drive unit or in a multi-screw configuration for a single lifting unit. Multi-screw units with mechanical synchronization are driven by a single motor, making them unsuitable for uneven load distribution and requiring high synchronization of lifting components. Multi-screw units with electrical synchronization have low requirements for mechanical connections but require more complex control components and systems. The configuration of the drive motor, combined with a master-slave layout, can achieve the necessary synchronization for the drive system.

Once the layout is set according to your requirements, it can be confirmed.: Worm gear reducer, gear reducer, couplings, connecting shafts, and dumbbell glaze. The installation of the bearing housing can be related to the length and speed of the connecting shaft.

ZBSeries ball screw lifters are suitable for high-speed, high-frequency, and high-performance devices.ZBSeries ball screw lifting machines are mainly composed of precision ball screw units and high-precision worm gear units, featuring high efficiency, ball friction, and improved overall efficiency with minimal driving power.Can generate a significant impetus.

Ball screw is an ideal product for converting rotary motion into linear motion, or vice versa. The structure of the ball screw lifting machine:

The structure of ball screw assemblies is traditionally divided into internal recirculation structures, represented by circular and elliptical reversers.) and the external circulation structure (represented by the pipe), both of which are commonly used structures. There is no fundamental difference in performance between the two structures; the only distinction is that the internal circulation structure has smaller installation and connection dimensions, while the external circulation structure has larger dimensions for the ball screw lifting machine. Currently, there are over 10 different structures for ball screw units, but the most commonly used ones are: internal circulation structure; external circulation structure; end cover structure; and cover plate structure.

Ball screw principle:

1. Ball screw actuators, in accordance with the national standard GB/T17587.3-1998 and application examples, are used to convert rotational motion into linear motion; or linear motion into rotational motion, featuring high transmission efficiency and precise positioning.

2. When the ball screw jack serves as the actuator, the nut converts the rotating angle of the screw into linear motion according to the specified pitch, allowing the passive workpiece to be connected to the nut bracket and nut to achieve the corresponding linear motion.

Ball screw features:

1、Ball screw vs. sliding screw, the driving torque is1/3

2、Ball screw with high precision_

3、Ball screw micro feed

4、Ball screw with zero side clearance and high rigidity

5、Ball screw high-speed feed possible.
