Gearshifters, also known as gear shift boxes or gear shifters, are a type of power transmission mechanism and form a series within reducers. They are widely used in the industrial sector. The products have now achieved standardization and a variety of specifications. Gearshifters can operate in both forward and reverse directions, providing smooth transmission at low or high speeds. They are available in single-axis, double transverse-axis, single longitudinal-axis, and double longitudinal-axis options; input on the transverse axis and output on the longitudinal axis results in reduction, while input on the longitudinal axis and output on the transverse axis results in an increase in speed.

T helical bevel gear reducer features:
1. Chassis: Made of high-strength FC-25 cast iron.
Gear: Made from high-purity alloy steel 50CrMnT, heat treated and ground after carburizing quenching process.
3. spindle: Made of high-purity alloy steel 40Cr, heat treated for high suspended load capacity.
4. Bearings: Equipped with heavy load capacity tapered roller bearings.
5. Oil Seal: Utilizes imported double唇 oil seal with superior dust and oil leakage prevention capabilities.

T Series Gearbox Directional Converter Model/Technical Parameters:
Model: T2, T4, T6, T7, T8, T10, T12, T16, T20, T25
Speed Ratio: 1:1, 1.5:1, 2:1, 2.5:1, 3:1, 4:1, 5:1 are all actual drive ratios.
Power Range: 0.015-300 kW
Torque Range: 7.15-5713 Nm
Available with single horizontal axis, double horizontal axis, single vertical axis, and double vertical axis.
