Technical Specifications:
Rated Voltage: AC100-240V, 50/60Hz; Power: 1250W/95W
Light Source: 100W/700W LED White Light Module Lifespan: 20,000 hours
Color Temperature: 7500K
Focus Adjustment: High-precision glass lens, 7°~50° linear high-speed adjustment
Zoom, evenly consistent light spot over any range
A graphic cutting system capable of generating geometric shapes in various sizes and forms, with the ability to rotate the graphics at any angle from 0° to 90°.
Rotary Pattern: 1 rotary pattern disc with 6 selectable pattern pieces, featuring variable vibration and bidirectional rotation, with 16-bit precision fine-tuning for pattern rotation.
Fixed Pattern: 1 fixed pattern disc featuring 8 selectable pattern slices, with variable vibration and bidirectional rotation. Effect Disc: 1 dynamic effect disc that can simulate dynamic effects like flames and flowing water.
Color Palette: 1 color disc contains 7 color chips, achieving a bi-directional rainbow effect, semi-color, and linear adjustment. CMY: Infinite color mixing
C To: Linear Color Temperature Adjustment
Aperture: 5 - 100% linear adjustment, featuring various macro effect functions
Flicker: Fast electronic flicker from 1-25 Hz per second, featuring pulse and synchronous/async flicker effects; Dimming: 0-100% electronic linear dimming
Diamond-shaped
Mirror: 1 quad prism, 1 four-row mirror; Variable speed bidirectional rotation; Independent fogging mirror: 1
Visual Index: 1 Independent Visual Index Lens
Display: 2.8-inch color touch screen, English and Chinese can be switched freely; Horizontal: 540° horizontal angle (16BIT precision adjustment), auto-correctable; Vertical: 270° vertical angle (16BIT precision adjustment), auto-correctable.
Control Modes: DMX512, RDM, Walk-Through, Voice Control, Scene, Master-Slave Mode, Optional wireless transmission control channel: 41 channels
Protection Level: IP20 Net Weight: 36 kg
Net Weight: 44 kg (1 pc per carton)
122 kg (2 units per aviation case)
Light fixture dimensions: 48*34*76 cm
