Features:

1. 1. Vertical mold, vertical injection molding, suitable for inserts forming.

2.2 Quick mold change, low-pressure clamping, automatic mold opening in case of anomalies, unique design.

3.3. Display of motion faults, repair is easy and straightforward.

4.4. Hydraulic components, quiet and durable.

5, 5, Segment temperature control, multi-segment injection pressure, injection speed, back pressure adjustment, suitable for plastic part molding.

6. The machine is equipped with either a single-mode slider or a dual-mode alternating slider. The bottom mold performs the insertion work on the outside, enhancing operationality and work efficiency. (The finished product is ejected externally, with the bottom mold featuring an independent ejector pin.)

7. Special wood material tube, heated and oiled by a mold temperature machine with temperature control, suitable for bakelite molding.

Technical Specifications:

Model	MODE	UNIT	YT-D35T-1S
*Injection System	INJECTION UNIT
Bolt diameter	Screw Poameter	mm	26	32
Feed pressure	Injection Pressure	Kgf/c	2071	1367
Theoretical Shot Volume	Injection Capacity	cm³	64	94
Large Injection Weight	Injection Weight(PS)	gr	57	87
Large Injection Weight	Injection Weight(PS)	oz	2	3
Injection type	Injection Rate	cm³/s	44	67
Screw rotation count	Screw Speed	r.p.m	0~180
Screw stroke	Screw Stroke	mm	120
Nozzle stroke	Nozzle Stroke	mm	150
Nozzle top force	Nozzle Contact Force	tf	2.4
*Screw mold system	CLAMPING UNIT
Mold Closing Method	Clamping System
Clamping Force	Clamping Force	tf	35
Mold Closing Stroke	Clamping Stroke	mm	215
Large space	Max.Nould Space	mm	360
Small model, thick	Min.Nould Height	mm	145
Template Size	Overall Size Of Platens(HxV)	mm	600×340
Internal Column Dimensions	Space Between Columns(HxV)	mm	450×240
Hydraulic Piercing Force	Hydraulc Ejector Force	tf	1.7
Pierce needle stroke	Ejector Stroke	mm	40
*Sliding Mode System	SLIPFORM
Sliding Stroke	Slidable Journey	mm	350
Sliding Mold Dimensions	Overall Size Of Slipfotm(HxV)	mm	390×390
Mold Station Count	Numbe Of Molds	sets	1
*Electrical machinery, other	ELETRICAL EQUIPMENT%GENERAL
Electric Motor	Drive Notor	kw	5.5(7.5HP)
Electric heating	Heater	kw	4.4
Mechanical dimensions	Dimenson Of Machine(LxWx)	m	1.6×1.2×3.1
Mechanical weight	Weight Of Machine	kg	1900
Packing dimensions	Shipping Size(LxWx)	m	1.8×1.4×2.5
Packing Weight	Shipping Weight	kg	2400
Fuel Tank Capacity	Oil Tark Capacity	l	160
Cooling Water Volume	Cooling Water	l/hr	600~800

Bakelite Vertical Injection Molding Machine (55 tons)

Features:

1. Vertical mold clamping, vertical injection molding, suitable for insert molding.

2. Fast mold closing, low-pressure locking, automatic mold opening upon abnormality, unique design.

3. Automatic fault display, easy and convenient for maintenance.

4. Electric and hydraulic components, quiet and durable.

5. Multi-stage temperature control, multi-stage injection pressure, injection speed, and back pressure adjustment, suitable for plastic part molding.

6. This machine is equipped with a single-mode slider or a dual-mode alternating slider. The lower mold performs the insertion work on the outside, enhancing operational and work efficiency. (The finished product is ejected externally, with an independent lower mold ejector pin.)

7. The material tube is a special wood tube, heated and oiled by a mold temperature machine for temperature control, suitable for bakelite molding.

Technical Specifications:

Model	MODE	UNIT	YT-D55T-1S
*Injection System	INJECTION UNIT
Bolt diameter	Screw Poameter	mm	30	40
Injection Pressure	Injection Pressure	Kgf/c	2057	1395
Theoretical Shot Volume	Injection Capacity	cm³	92	176
Large Injection Weight	Injection Weight(PS)	gr	83	158
Large Injection Weight	Injection Weight(PS)	oz	2.9	5.5
Injection Type	Injection Rate	cm³/s	55	94
Screw rotation count	Screw Speed	r.p.m	0~180
Screw Stroke	Screw Stroke	mm	130
Nozzle stroke	Nozzle Stroke	mm	200
Nozzles' Top Force	Nozzle Contact Force	tf	3.5
*Nut Molding System	CLAMPING UNIT
Mold closing method	Clamping System
Clamping Force	Clamping Force	tf	55
Mold Closing Stroke	Clamping Stroke	mm	200
Large space	Max.Nould Space	mm	380
Small and thick	Min.Nould Height	mm	180
Template Size	Overall Size Of Platens(HxV)	mm	650×400
Bushing internal dimensions	Space Between Columns(HxV)	mm	490×240
Hydraulic Piercing Force	Hydraulc Ejector Force	tf	1.7
Punch needle travel	Ejector Stroke	mm	40
*Sliding System	SLIPFORM
Slider Stroke	Slidable Journey	mm	400
Sliding Mold Size	Overall Size Of Slipfotm(HxV)	mm	460×460
Mold Station Count	Numbe Of Molds	sets	1
*Electrical machinery, others	ELETRICAL EQUIPMENT%GENERAL
Electric Motor	Drive Notor	kw	7.5(10HP)
Electric heating	Heater	kw	4.9
Mechanical dimensions	Dimenson Of Machine(LxWx)	m	1.85×1.3×3.2
Mechanical weight	Weight Of Machine	kg	2900
Packing Dimensions	Shipping Size(LxWx)	m	2.05×1.5×2.5
Packing Weight	Shipping Weight	kg	3500
Fuel Tank Capacity	Oil Tark Capacity	l	220
Cooling Water Quantity	Cooling Water	l/hr	600~800

High-speed Vertical Injection Molding Machine (85 tons)

Features:

1. Vertical mold closing, vertical injection molding, suitable for insert molding.

2. Quick mold closing, low-pressure locking, automatic mold opening in case of abnormality, unique design.

3. Automatic fault display for easy repair.

4. Components for electric and hydraulic control are quiet and durable.

5. Multi-stage temperature control, multi-stage injection pressure, nitrogen accumulator for energy storage, back pressure adjustment, suitable for plastic part molding.

Technical Specifications:

	ModelModel	Unit	YT-85T-GS
Injection system	Screw diameterScrew Diameter	mm	22	26
	Theoretical Shot CapacityTheorfical Shot Volume	cm³	26.7	32.9
	Injection Volume(PS)Max.shot Weight(PS)	g/0z	26/0.9	30.6/1.1
	Molding YieldInjection Rate	cm²/see	158	267
	Injection PressureInjection pressure	kgf/cm²	2811	2100
	Screw speedScrew Speed Max	rpm	0-380
Locking system	Molding ForceClampieng Force	tf	85
	Mold Opening JourneyOprening Stroke	mm	250
	Small model thickMin.Mold Height	mm	230/330
	Wide pitchMax.Mold Height	mm	480/580
	Template SizePlateu Size	mm	680*570
	Mold column spacingDisitance Betqeen Tie Bare	mm	500*385
	Top Travel ItineraryEjector Strke	mn	5
	Ejection ForceEjector Stroke	tf	2.7
Other	High hydraulic pressureMax.Hydaulic Pressure	Kgf/cm²	140
	Actuating Oil VolumeOil Resservoir Capacity	l	180
	Motor PowerPump Motor Power	kw	11（15HP）
	Electrical heating capacityBorrl Heating Power	kw	5.6
	Machine dimensionsMachine Dimensions(LxWxH)	mm	350015002500
	Total Machine WeightMachine Weight	kg	5000
