RX53M Research-grade Inverted Metallographic Microscope

Optical System

Optical System with Infinite Color Difference Correction

Optical Magnification Ratio

50x - 1,000x

Digital Magnification Ratio

150x-3,000x (21.5" monitor) with 100x objective magnification, up to 3,000x total magnification

Observation tube

Just like the infinite-far three-eye observation scope with adjustable interpupillary distance: 50mm to 76mm; two-stage spectral ratio: 100:0, 0:100.

Aspherical, Infinite Distance Pivot Three-Eye Scope, Pupillary Distance Adjustment Range: 50mm ~ 76mm; Two-Stage Spectral Ratio: 100:0, 50:50

Eyepiece

High Eye Point Wide Field Binocular Eyepiece PL1023mm, adjustable field of view

Objective lens

Infinite working distance brightfield semi-apochromatic metallographic objective, 2.5X

Infinite working distance semi-apochromatic bright-field optical objectives, magnifications of 5X, 10X, 20X, 50X, and 100X

Infinity Long Working Distance Semi-Apochromatic Bright/Dark Field Metallographic Objective 5X, 10X, 20X, 50X, 100X

Infinity long working distance fully corrected achromatic bright/dark field metallographic objectives 10X, 20X, 50X, 100X

Objective Converter

5-Pin Bright/Dark Field Converter (with DIC Slot)

5-Pin Encoding Day/Night Field Switchable Middle Focal Converter (with DIC Slot)

The encoded objective converter integrates the microscope's hardware settings with the Omicron image analysis software. It displays the magnification of the objective on the screen and automatically adjusts the calibration values recorded in the software when switching magnifications, eliminating measurement errors caused by forgetting to switch the software magnification.

5-Pin Encode Type Bright/Dark Field Motorized Objective Converter (Motorized/with DIC Slot)

Rack

Reflector Mount for透反射, featuring a low-hand position coarse-fine coaxial focusing mechanism. Coarse adjustment travel of 35mm, fine adjustment accuracy of 0.001mm. Equipped with a tension adjustment device to prevent sliding and a random upper limit device. Includes light intensity setting and reset function.

Cargo Platform

4-inch cargo platform, travel: 105mm x 102mm mechanical platform, coaxial adjustment in X and Y directions.

Converging lens

Shaker-Type Apochromatic Condenser Lens (N.A. 0.9)

Reflective lighting fixture

Dimming and brightening field reflector with variable aperture diaphragm, field stop, center adjustable, with filter holder, with polarizer/ analyzer holder.

Lamp Room

10W adjustable LED light room, universal in transmission and reflection, pre-order center

Polarized Components

Polarizing beam splitter plate, 360° rotating polarizing beam splitter plate

Additional Attachments

Photography & Video Accessories: 1X, 0.65X, 0.5X C-mount, adjustable focus.

4K high-definition imaging system, USB3.0 computer imaging system, cameras (5MP, 6MP, 12MP, 20MP, etc.)

High-precision micrometer caliper, graduation value 0.01mm

Software (Professional Measurement Systems, Metallographic Analysis Systems, Particle Analysis Systems, Porosity Analysis Systems, Welding Measurement Systems, etc.)
