Product Description

Due to extensive sedimentation at the riverbed, a large accumulation of algae forms on the water surface, blocking the natural exchange of air and water. This results in severe hypoxia at the bottom, leading to fish deaths, the extinction of aquatic plants, and the loss of self-purification capabilities. Photovoltaic microporous aeration machines, powered by photovoltaic energy, drive fans to increase oxygenation in the water's deep layers, eliminate water stratification, reduce the gradual mineralization of bottom mud, and restore the water's self-purification ability. They utilize solar energy to maintain the water's metabolism over the long term.

Product is mainly used for aeration in waterways, with better diffusion capability than impeller-type aeration machines. It employs a main gas supply line and a lead gas channel, along with a rubber membrane with expandable holes for micro-porous aeration. It features a simple structure, high oxygen utilization rate, reliable performance, non-blocking air holes, no backflow of wastewater, uniform circumferential stress, long lifespan, easy installation and maintenance, and cost-effective system pricing. It is currently one of the more economical and reasonable aeration machines available.

Product Structure:

·Solar Microbubble AeratorPrimarily composed of photovoltaic panel components, high-pressure blower aeration machines, microporous release devices, battery packs, and control systems. The microporous release devices utilize fixed microporous aeration disks or microporous aeration tubes to release tiny bubbles, extending the gas's residence time in water, which is beneficial for oxygen transfer and improves oxygenation rates, enhancing aeration efficiency.

● Utilizes a tubular structure, significantly reducing the tension on the membrane compared to disk-type aeration.

● Employed leading air channel structure, the aeration components have no buoyancy.

● The film uses natural rubber and anti-aging formula, ensuring long-lasting usage.

●Utilizes stainless steel fasteners for connection, ensuring airtight interfaces and easy disassembly.

Operating Principle:

Photovoltaic electricity powers the wind turbine to rotate at high speed, compressing air into a microporous release device, allowing the water to fully contact with the tiny bubbles, forming a gas-water mixture. This utilizes the rising water current caused by bubble formation to control the accumulation of sediment and sludge, maintaining a uniform dissolved oxygen level throughout the water body. By increasing oxygen, it promotes the aerobic decomposition of pollutants in the water, effectively preventing anaerobic digestion and controlling the臭味 of decay, ultimately establishing an ecological balance for the water body's self-purification.

Features:

●High oxygen utilization, even distribution of air, no clogging;

●Long service life, no condensation inside the air tube, stable and reliable performance;

●Simple installation structure, no buoyancy in the air tube, convenient design for use

Solar-powered, no wiring required, zero operating costs.

Application Scope:

Reservoirs, rivers, lakes, streams, ponds, and dead lakes are suffering from severe hypoxia in the deep water layers.Water with high nutrient sediment contentIncrease dissolved oxygen levels for calcification, reduce sediment.

Specification and Main Performance Parameters:

Installation Method

1. Integrated Cable Fastening 2. Integrated Anchor Fastening 3. Integrated Piercing Fastening 4. Integrated Cantilever Fastening 5. Disassembled Fastening
