Product Details
High-Precision Honing and Boring Equipment Manufacturer
产品Price Negotiable
最小起订Quantity： 供货总Quantity：
Serial Number Project Name Parameters 1 Structural form Number of shaft ends: 1 shaft Workstation: 1 workstation Desk Top Size: 1250mm*900mm Workbench Load: 500kg 2 Spindle Mechanism Control Method: Variable Frequency Motor + Synchronous Belt Spindle Motor: 2.2KW Machining Hole Diameter Range: Φ2-Φ60mm (optional in sizes outside this range) Gear ratio range: 50-3,000 rpm (Continuous variable speed) 3 Cylinder mechanism Control Method: Servo Motor + Ball Screw Stroke Speed MAX: 40m/min Stroke Length MAX: 350mm 4 Feeding Mechanism Control Method: Servo Motor + Ball Screw Feeding Type: Constant Feed Rate Feeding Resolution: 0.1um 5 Other Equipment Weight: Approximately 2.5 tons Equipment dimensions (Length x Width x Height): 1500x1500x2350 Noise Standard: In standard factory settings, continuous loading peak noise level is less than 75 decibels. Power Supply: Three-phase AC: 380V 50Hz Environmental Conditions: Temperature -10~+45°C
Temperature < 72%
