Product Details
High-Precision Honing and Boring Equipment Manufacturer
产品Price Negotiable
最小起订Quantity： 供货总Quantity：
I. Equipment Specifications Section II: Key Equipment Description 1. Equipped with a "Siemens" control system and featuring a touch screen, the machine allows for flexible adjustment of stroke positions, spindle speeds, and feed pressures, ensuring optimal control over bore precision. 2. The machine tool is equipped with a comprehensive cooling filtration system, mainly consisting of a "magnetic separator + belt filter," with a filtration precision of ≤30um. 3. The equipment features short stroke and pause stroke functions, facilitating the correction of hole shapes. 4. The cutting head features an automatic expansion and contraction system with adjustable pressure control. 5. Processing methods available for either "fixed quantity" or "fixed pressure," switchable at will. 6. Equipped with a shift transmission, the device allows for easy adjustment of spindle torque and speed according to the hole diameter. 7. The equipment features an NC-controlled overload protection system. 8. The equipment features an automatic wear compensation system for abrasive stones.
Serial Number Project Parameters 1 Processed Hole Diameter Φ20-Φ300mm (optional sizes available outside this range) 2 Spindle Drive High and low speed transmission + CVT 3 Spindle Speed 10-350R PM 4 Stroke method Servo Motor 5 Stroke speed 40m/min 6 Stroke Length 1000m m 7 Feeding Method Servo Motor + Customized Screw 8 Feed Resolution 1um 9 Cooling System Flow rate: 50/min; Capacity: ≥300L 10 Standard fixture holds outer diameter 28-380mm 11 Dimensions 4600mm* 1200mm*1700mm 12 Machine tool weight 2.8 tons
