Product Details
High-Precision Honing and Boring Equipment Manufacturer
产品Price Negotiable
最小起订Quantity： 供货总Quantity：
I. Equipment Specifications Section II: Equipment Processing Precision Circularity: ≤1um 2. Cylindericity: ≤2um/100mm 3. Roughness: ≤Ra0.1μm. Section 3: Key Equipment Descriptions All machine tool base components are made of high-quality cast iron with high strength and undergo overall stress relief treatment. 2. Advanced touch screen control panel, simple and convenient to adjust settings, enabling operators to handle machine tools more intuitively. 3. Equipped with a Siemens control system, it ensures excellent shape accuracy, wire angle, surface roughness, and dimensional consistency through precise control. 4. The machine tool is equipped with a comprehensive cooling and filtration system, mainly composed of "magnetic separator + belt filter + oil cooler", with a filtration accuracy of ≤20um. 5. The machine tool is equipped with a centralized automatic lubrication system, providing a continuous supply of lubricant to all functional components.
Serial Number Project Name Parameters 1 Structural form Axle Head Count: 2-axis Workstation: 2 Workstations Workbench Surface Size: 1250*900 Workbench Capacity: 500kg . 2 Spindle Mechanism Control Method: Variable frequency motor + synchronous belt Spindle Motor: 2.2KW Processing Hole Diameter Range: Φ2-Φ60mm (optional in other sizes) Transmission Range: 50-3000 rpm (Continuous variable speed) 3 Stroke mechanism Control Method: Servo Motor + Ball Screw Stroke Speed MAX: 40m/min Stroke Length MAX: 350mm 4 Feeding Mechanism Control Method: Servo Motor + Ball Screw Feeding Type: Constant Feed Rate Feeding Resolution: 0.1um 5 Other Equipment Weight: Approximately 4.0 tons Equipment dimensions (Length x Width x Height): 1500*1500*2350 Noise Standards: Under standard factory conditions, less than 75 decibels under continuous peak loading Power Supply: Three-phase AC: 380V 50Hz Environmental Conditions: Temperature -10~+45°C
Temperature < 72%
