Product Details
High-Precision Honing and Boring Equipment Manufacturer
产品Price Negotiable
最小起订Quantity： 供货总Quantity：
Section 1: Equipment Specifications Section II: Equipment Processing Precision Circularity: ≤1um 2. Cylindricity: ≤2um/100mm 3. Roughness: ≤Ra0.1um. Section 3: Key Equipment Description All machine tool base components are made of high-quality cast iron with high strength and undergo overall stress relief treatment. 2. Advanced touch screen control panel for easy and convenient setting adjustments, allowing operators to handle machine tools more intuitively. 3. Equipped with a "Siemens" control system, precise control ensures excellent shape accuracy, pattern angle, surface roughness, and dimensional consistency. 4. The machine tool is equipped with a comprehensive cooling filtration system, primarily consisting of a "magnetic separator + belt filter + oil cooler," with a filtration accuracy of ≤20um. 5. The machine tool is equipped with a centralized automatic lubrication system, providing a steady supply of lubricant to all functional components.
Serial Number Project Name Parameters 1 Structural Form Number of shaft ends: 1 shaft Workstation: 1 workstation Worktop Size: 1250*900 Workbench Load: 500kg . 2 Spindle Mechanism Control Method: Variable Frequency Motor + Synchronous Belt Spindle Motor: 2.2KW Machining hole diameter range: Φ2-Φ60mm (optional in other sizes) Transmission Range: 50-3000 rpm (Continuous variable speed) 3 Stroke mechanism Control Method: Servo Motor + Ball Screw Stroke Speed MAX: 40m/min Stroke Length MAX: 350mm/ 600mm 4 Feeding mechanism Control Method: Servo Motor + Ball Screw Feeding Type: Constant Feed Rate Feed Resolution: 0.1um 5 Others Equipment Weight: Approximately 2.5 tons Equipment dimensions (length x width x height): 1500x1500x2350 Noise Standard: In standard factory environments, less than 75 decibels under continuous loading peak. Power Supply: Three-phase AC: 380V 50Hz Environmental Conditions: Temperature -10~+45°C
Temperature < 72%
