Unit Parameter NW1332B×1000 NW1332B×1500 NW1332B×2000 NW1332B×3000General capabilitiesCenters at mm 1000, 1500, 2000, 3000 with a height of mm 180, grindable outer diameter range φ8 to 320, grindable outer diameter length mm 1000, 1500, 2000, 3000, grindable workpiece weight kg 150HeadstandCenter cone MT5 spindle speed: 25, 50, 75, 110, 150, 220 rpmTailstockCenter cone MT4 tailstock sleeve manual movement mm30Grinding Wheel StandGrinding wheel spindle speed: 1100 rpm, rapid feed rate: 50 mm, large movement: 235 mm, handwheel rotation movement: 2 mm coarse / 0.5 mm fine, handwheel one division movement: 0.01 mm coarse / 0.0025 mm fine, grinding wheel large size: φ600×63×305, grinding wheel linear speed: 35 m/sWorkbenchHandwheel turn, workbench movement 6mm; large workbench rotation angle: clockwise 3°, 2°, counterclockwise 7°, 6°, 3°, 3°; workbench longitudinal movement speed range: 0.1~4 m/min.MotorGrinding Wheel Stand Motor Power: 11kw; Headstock Motor Power: 0.75/1.5kwMachine ToolMachine Tool Weight: T3.7, 4.5, 6.7; Packaging Volume (Length × Width × Height) mm: 3220×2000×2050, 4220×2000×2050, 5400×2000×2050, 7390×2000×2050
