WDZN-YJY23 Power Cable, Armored Halogen-Free Low Smoke Fire-Resistant Cable

Anhui Tianming Cable Co., Ltd. --- WDZN-YJY23 Power Cable - Armored Halogen-Free Low-Smoke Fire-Resistant Cable, produced in accordance with national standards GB/T18380, GB/T19216, GB/T17651, GB/T17650, and international standards.

Low-smoke, halogen-free flame-retardant cables are difficult to ignite and possess the ability to prevent or contain fires. Moreover, once ignited, they exhibit halogen-free, low-smoke, non-toxic, and non-corrosive properties. They are suitable for applications such as high-rise buildings, hotels, hospitals, subways, nuclear power plants, tunnels, power plants, mines, oil, and chemical industries. The power cable WDZN-YJY23, armored halogen-free low-smoke flame-retardant cable, not only meets the characteristics of low-smoke, halogen-free flame-retardant cables but also ensures circuit power supply under fire conditions. It is mainly used in fire alarm systems, fire-fighting equipment, smoke extraction systems, and emergency facilities such as emergency exit lighting, where fire resistance is required.

Two, Cable Structure:

Conductor: Bare copper wire or tin-plated copper wire, solid-core, multi-core braided, or fine strands twisted into bundles, conforming to GB/T 3956 and IEC 60228 *** Class (Class A), Category 2 (Class B), or Category 5 (soft stranded).

Insulation: Poly (PE), Cross-linked Poly (XLPE).

Armored Layer: Double steel strip or galvanized steel wire armor, galvanized steel wire braid armor, or copper wire braid armor (the braid density shall not be less than 65%).

Screening Layer: Copper wire or tin-plated copper wire braiding, copper-plastic or aluminum-plastic composite tape wrapping, and aluminum-plastic composite tape copper wire braiding combination screening.

Sheath: Low-smoke, halogen-free flame-retardant polyolefin.

Core Wire Identification: Color marking or white numbering printed on black core wire.

Three, Product Model:

Computer Cable, Flame-retardant Cable, Cross-linked Cable, High-temperature Cable, Silicone Rubber Cable, Compensation Cable, Flat Cable, Cold-resistant Cable, Sheathed Cable, Flame-retardant Cable, RF Cable, Instrument Cable, Shielded Cable, Control Cable, Steel Wire Armored Cable
