Anhui Tianming Cable Co., Ltd. - ZC-DJYJP2VRP2 Flame Retardant Computer Cable: Shielded cable for instrument signal cables used primarily in electronic computers for automatic control systems, particularly suitable for computer distributed control systems. It transmits analog and digital signals for the detection, control, and alarm of production facility process variables. The product is manufactured using paired twisting, separate screening, and overall screening processes, thus offering excellent resistance to magnetic and static interference.

2. Product Model:

Model Product Name
ZC-DJYVP Copper-core insulated flame-retardant sheathed copper wire braid shielded instrument signal cable
ZC-DJYJVP Copper-core cross-linked poly-insulation flame-retardant poly sheath copper wire braid shielded instrument signal cable
ZC-DJYVRP Copper-core insulated flame-retardant sheathed copper wire braid shielded instrument signal cable
ZC-DJYJVRP Copper-core cross-linked poly-insulating flame-retardant sheathed copper wire braid shielded instrument signal cable
ZC-DJYPVP Copper-core insulated flame-retardant sheathed copper wire braid, split and main screen instrument signal cables
ZC-DJYJPVP Copper-core cross-linked poly-insulating flame-retardant sheathed copper wire braided screening, total screen, and meter signal cables
ZC-DJYPVRP Copper-core insulated flame-retardant sheathed copper wire braided screening, main and auxiliary panel instrument signal flexible cables
ZC-DJYJPVRP Copper-core cross-linked poly-insulated flame-retardant sheathed copper wire braided for partition and main panel instrument signal flexible cables
ZC-DJYVP3 Copper-core insulated flame-retardant polyethylene sheathed aluminum-plastic composite tape-wrapped shielded instrument signal cable
ZC-DJYJVP3 Copper-core cross-linked poly-insulating flame-retardant poly sheath aluminum-plastic composite tape-wrapped shielded instrument signal cable
ZC-DJYVRP3 Copper-core insulated flame-retardant polyurethane sheathed aluminum-plastic composite banded shielded instrument signal soft cable
ZC-DJYJVRP3 Copper-core cross-linked poly-insulating flame-retardant poly sheath aluminum-plastic composite insulated wire for shielding instrument signal soft cable
ZC-DJYP3VP3 Copper-core insulated flame-retardant polyethylene sheathed aluminum-plastic composite tape-wrapped, split-screen, and total-screen instrument signal cables
ZC-DJYJP3VP3 Copper-core cross-linked poly-insulation flame-retardant poly sheath aluminum-plastic composite tape-wound, separately screened and total screen instrument signal cables
ZC-DJYP3VRP3 Copper-core insulated flame-retardant polyethylene sheathed aluminum-plastic composite tape wrapped, split-screen and total-screen instrument signal flexible cables

Three, Usage Features

1. rated voltage for communication: (U0/U) 300/500V

2. Long-term allowable operating temperature for cable conductor: Polyethylene 70℃; Cross-linked polyethylene 90℃

3. Lower environmental temperature: Fixed installation: -40°C, non-fixed installation: -15°C

Installation Temperature: Not less than 0℃

5. Recommended bend radius for installation: The copper braid shielded cable should be no less than 12 times the cable's outer diameter, while the cables with other structures should be no less than 6 times the cable's outer diameter.

Four, ZC-DJYJP2VRP2 flame-retardant computer shielded cable
Title 1: Cable Introduction and Flame Retardant Features
Computer cables are cables used to connect computers with external devices for the transmission of signals or data. The ZC-DJYJP2VRP2 flame-retardant computer shielded cable is a high-performance cable specifically designed for computer systems, featuring excellent anti-interference and flame-retardant properties.
Flame-retardant characteristics refer to the ability of cables to delay the spread of flames under extreme conditions such as fires. The ZC-DJYJP2VRP2 flame-retardant computer shielded cable is made with flame-retardant materials, which can effectively prevent the spread of fire during a fire, ensuring the safety of users and equipment.
Title II: Shielding Structure and Interference Resistance
The ZC-DJYJP2VRP2 flame-retardant computer shielding cable utilizes a multi-layer shielding structure, including foil shielding and braid shielding, which enhances the cable's interference resistance capabilities.
Aluminum foil shielding effectively blocks external electromagnetic interference, ensuring more stable and reliable signal transmission. Additionally, woven shielding further enhances the protective effect, offering higher anti-interference capability, and guaranteeing the stability and accuracy of data transmission.
Section III: Material Selection and Advantages
The flame-retardant computer shielding cable ZC-DJYJP2VRP2 utilizes materials like low-smoke, halogen-free flame-retardant materials, which do not emit harmful gases at high temperatures, ensuring safety for users and equipment.
Additionally, the cables utilize high-purity conductor materials with excellent electrical conductivity and corrosion resistance, ensuring stable and accurate signal transmission. Moreover, the outer sheath of the cables is made from high-strength, pressure-resistant materials, offering robust resistance to physical damage, thereby extending the cable's service life.
Section IV: Application Fields and Market Demand
ZC-DJYJP2VRP2 flame-retardant computer shielding cables are widely used in various computer systems, such as data centers, communication base stations, and automated equipment, meeting the demand for high-performance cables in these fields.
With the continuous development of computer technology and the increasing number of application scenarios, the requirements for cables have also become higher. Flame-retardant computer shielded cables can effectively reduce the harm of fires to equipment and personnel, enhancing safety; at the same time, the application of materials and shielding structures endows the cables with excellent anti-interference capabilities, ensuring stable data transmission and meeting market demands.
The ZC-DJYJP2VRP2 flame-retardant computer shielding cable has been widely used in the computer system field due to its performance. Whether ensuring user and equipment safety or meeting the demands of high-performance cables, the ZC-DJYJP2VRP2 flame-retardant computer shielding cable delivers exceptional performance. With technological advancements and increased application scenarios, it is believed that the market demand for this cable will continue to grow.
