Anhui Tianming Cable Co., Ltd. produces the YGCB 0.6/1KV silicone rubber flat cable in Anhui, which is a high-temperature-resistant flat cable widely used for connecting electrical and mechanical equipment in various high-temperature environments. The following are some of the cable's main features and application scenarios:

Key Features:

High-temperature resistance: The silicone rubber insulation and sheath materials enable it to work stably in high-temperature environments for a long period. The temperature range it can typically withstand is from 60℃ to +180℃, and it can reach +200℃ temporarily.

2. Flat Structure: The flat cable design makes it more convenient for installation and wiring, particularly suitable for limited space applications.

3. Corrosion-Resistant: Silicone rubber materials offer excellent resistance to chemical corrosion, suitable for various harsh environments.

4. Good Flexibility: The cable has excellent flexibility, making it easy to bend and move for use.

5. Excellent Aging Resistance: Silicone rubber materials offer superior aging resistance, thereby extending the service life of cables.

6. Excellent Electrical Performance: The cable features excellent electrical insulation properties, suitable for voltage levels of 0.6/1KV.

Application Scenarios:

1. Metallurgical Industry: Electric power transmission for high-temperature furnaces, heating equipment, and similar applications.

2. Chemical Industry: Electrical equipment connections for corrosive environments.

3. Equipment: Mobile devices for various high-temperature, high-humidity, and corrosive environments.

4. Power Industry: Used for power transmission and distribution in high-temperature environments.

5. Other Industries: Suitable for applications requiring cables with high-temperature resistance, corrosion resistance, and good flexibility.

Technical Specifications:

Rated Voltage: 0.6/1 kV

Conductor Material: Copper Conductor

Insulating Material: Silicone Rubber

Insulation Material: Silicone Rubber

Temperature Range: 60℃ to +180℃ (short-term up to +200℃)

Bend Radius: Typically 6 to 10 times the cable's outer diameter, depending on cable specification.

Cautionary Notes:

Avoid mechanical damage to the cable during installation and use.

2. The bending radius of the cable should meet the requirements to prevent excessive bending that may damage the cable.

3. When used in high-temperature environments, ensure that the cable has good heat dissipation to prevent overheating.

Anhui-produced silicone rubber flat cables, YGCB 0.6/1KV, are an ideal choice for power transmission in high-temperature environments, thanks to their superior performance and wide range of applications.
