Anhui Tianming Cable Co., Ltd. produces the YGCB 0.6/1KV silicone rubber flat cable in Anhui, which is a high-temperature-resistant flat cable widely used for connecting electrical and mechanical equipment in various high-temperature environments. The following are some of the cable's main features and application scenarios:

Key Features:

1. High Temperature Resistance: Silicone rubber insulation and sheath materials allow for long-term stable operation in high-temperature environments, typically with a temperature resistance range of 60℃ to +180℃, with short-term capability up to +200℃.

2. Flat Structure: The flat cable design makes installation and wiring easier, especially suitable for limited-space environments.

3. Corrosion-Resistant: Silicon rubber materials exhibit excellent chemical resistance, suitable for various harsh environments.

4. Excellent flexibility: The cable boasts good flexibility, making it easy to bend and move for use.

5. Excellent aging resistance: Silicone rubber materials possess excellent aging resistance, extending the service life of the cable.

6. Excellent Electrical Performance: The cable boasts superior electrical insulation properties, suitable for voltage levels of 0.6/1KV.

Application Scenarios:

1. Metallurgical Industry: Power transmission for high-temperature furnaces and heating equipment.

2. Chemical Industry: Electrical equipment connections for corrosive environments.

3. Machinery and Equipment: Mobile equipment designed for use in various high-temperature, high-humidity, and corrosive environments.

4. Power Industry: Used for power transmission and distribution in high-temperature environments.

5. Other Industries: Suitable for applications requiring cables with high-temperature resistance, corrosion resistance, and good flexibility.

Technical Specifications:

Rated Voltage: 0.6/1 kV

Conductor Material: Copper Conductor

Insulating Material: Silicone Rubber

Insulation Material: Silicone Rubber

Temperature Range: 60℃ to +180℃ (short-term up to +200℃)

Bend Radius: Typically 6 to 10 times the cable's outer diameter, depending on cable specifications.

Cautionary Notes:

During installation and use, avoid mechanical damage to the cable.

2. The cable bending radius should meet the requirements to prevent over-bending and potential cable damage.

3. When using in high-temperature environments, ensure good cable heat dissipation to avoid overheating.

Anhui-made silicone rubber flat cable YGCB 0.6/1KV, with its superior performance and wide range of applications, is an ideal choice for power transmission in high-temperature environments.
