Mitsubishi Signal Output Digital Indicator 543-350-10

Mitsubishi Signal Output Digital Indicator 543-350-10

543 Series

Signal Output Type Absolute Digital Indicator ID-C112JX2

● The indicator can output GO/ ± NG judgment results. Data can be output to sequence generators and other external devices, which is helpful

Enhance measurement automation. Reverse output logic also available.

● The GO/ ± NG judgment results can also be displayed on the main display unit and the dual-color LED, making it easy for direct assessment.

● Equipped with peak detection function, capable of making GO/ ± NG judgments for peak values and fluctuations.

● Utilizes the Sanwa-developed Origin ABS (ABSOLUTE) sensor, no need for origin recovery* each time power is turned on.

No overspeed errors will occur, offering exceptional reliability.

■ Features

External Output: -NG / OK / +NG Signal

N-ch Collector Open Drain

(Reverse Output Logic)

(Unable to output measurement data)

● External Control: Peak Start

Pre-set / Zeroing

Peak Detection Function (High/Low)

● Amplitude Detection Function (Difference between high and low values during movement)

Zeroing Function (INC Measurement System Origin Setting)

● Pre-set Function (ABS Measurement System Origin Setting)

● Count Direction Conversion Function

● Tolerance Judgment Function (ABS 3 sets, INC can store)

Resolution Switch Function

●Simple Calculation Function f(x) = Ax

● Function lock feature

Calibration Mode (External Output Becomes Digimatic Output)

● Error Warning Display

Select Options

● Measuring Rod Extension Option *

Measuring Rod Lift Rod: No. 21EZA198

Rod Elevator Button: No.21EZA105

No dust or water resistance guarantee.

● Digital Power Unit: No. 21EZA345

In Calibration Mode, using the i-Checker IC2000 and similar devices for self-

For dynamic detection use.

In this case, please purchase the connecting cables.

Cable Connector: No.21EAA194 (1m)

Or No.21EAA190 (2m)

Note: Under standard mode operation, it cannot be used as a power supply device.

● Mitutoyo dial indicator with various measuring heads (options)

▶ For detailed information, please refer to pages 07-49 to 07-54.

● Various Rear Covers (Options) ▶ For detailed information, please refer to pages 07-55 to 07-56.
