Mitsubishi Electric 543-340B-10 Digital Indicator with Calculator

Mitsubishi Calculating Digital Indicator 543-340B-10

543 Series

Absolute Digital Indicator ID-C112RXB2

● Integrated measuring rod displacement calculation feature. By setting installation calculation coefficients on various fixtures, measurement results can be directly read.

The "Fruit" is a highly scalable indicator.

● By connecting to the computer and using the parameter setting kit (optional) and software, various settings can be made.

● With 5 buttons, status icons, and button-assisted displays, simple operation achieves rich functionalities.

■Feature

● Calculation Function f(x)' ) = Ax'+ B + Cx' -1 ( x= x plus offset

Peak Detection Function (High/Low)

● Function for detecting amplitude fluctuation (difference between high and low values during motion)

Note: Peak detection capability

Sample Rate: 10 times per second

② Capture Speed: 10 µm/sec

By setting

Sample Rate: 50 times per second

② Capture Speed: 50 µm/second

Can switch

Zeroing Function (INC Measurement System Origin Setting)

● Preset Function (ABS Measurement System Origin Setting)

● Tolerance Judgment Function (ABS: Three Sets, INC: Can Store)

● Simulated division value switch

● Function Lock Feature

● Display Value Hold Function (No External Device Connected)

Data Output Function

External PC Setting Input Function

● Display Section Rotation Function (330°)

Low Voltage Warning Display

● Error Warning Display

● Resolution Switching Function

■ Options ▶ Detailed information can be found on pages 07-11.

● Measuring Rod Lift Option

Measuring Rod Lift Rod: No. 21EZA198

Lever for Measuring Rod: No.21EZA105
