Mitutoyo Sanwa Coolant-Resistant Caliper 500-723-20

Mitutoyo Sanfeng Cooling Fluid Caliper 500-723-20

500 Series

IP67 ABSOLUTE Coolant-Resistant Caliper CD-PS/PM

● This is a workshop digital caliper with an impressive IP67 protection rating and excellent environmental resistance. It can be safely used even in environments where a large amount of coolant is splashed. Moreover,

Digital displays prevent misreading of measurement results and reduce human error.

●Integrated with an ABS ruler featuring a zero-point, no need to reset to zero each time the power is turned on. Additionally, no overspeed errors will occur.

No screwdriver needed to open the battery cover; battery replacement is quick and easy.

● Models with data output ports can be connected to measurement data networks and statistical process control systems. See page 09-3 for details.

● The series caliper jaws are made of hard alloy, making them an ideal choice for measuring rough machined products, castings, grinding stones, and more.

■Features

Origin Setting: The origin position is adjustable.

Data Output: Equipped with a measurement data output port, capable of constructing a measurement data network system and statistical process control system.

Note: CD-P15S and P20S are excluded.

Automatic Power Supply:

On/Off

After 20 minutes of stationary time, the LCD screen

Automatic shutdown, origin saved. When the scale frame moves,

Display Recovery.

Error Alert: If a calculation error occurs on the display screen, it will show

Error message, stop measurement. If battery voltage drops,

"B" light illuminates before measurement, alerting users to battery consumption.
