Japan Magnescale Magnetic Scale SR128-040

Japanese Magnescale Magnetic Scale SR128-040

Product Introduction

Magnescale Scale Tape SR128 | Scale Tape

Magnetic Scale SR128 Series: Designed for use in chip-cutting machinery or applications requiring positioning. Features include oil resistance, vibration resistance, anti-pollution, and durability; simple structure, long service life, and the same thermal expansion coefficient as metal. GB Series Magnescale (magnescale), compact in design, with a cross-sectional dimension of 25x21mm.

Product quality:

Oil-resistant, dust-resistant, vibration-resistant, and adaptable to various environments.
2. Compact and clever design, saving installation space.
3. Magnetic, built-in origin.
4. Suitable for use on milling machines, grinding machines, and other general machine tools.

5. Simple structure, long lifespan, and the same coefficient of thermal expansion as metal.

Linear Ruler
Lengths available: 50, 100, 150, 200, 250, 300, 350, 400, 450, 500, 550, 600, 650, 750, 850, 950, 1050, 1250, 1400, 1600, 1850, 2050, 2200mm
Length: +104mm (Length under 200mm available)
Length +120mm (over 200mm)
Maximum Length: Length + 14mm (Length below 200mm, 7mm on each side)
+30mm in length (less than 250mm in length, 15mm on each side)
Direct Line Scale Accuracy (20℃): ±5μm (SR128 series)
Key Points:
1. Compact and lightweight
2. Easy installation
3. Temperature coefficient of expansion is the same as mechanical
4. Height and Position
5. Oil and dirt-resistant

Product Specifications:

Product Model:
