Mitutoyo Sensitive High Precision Digital Micrometer 293-142-30

Mitutoyo High-Precision Digital Micrometer 293-142-30

Achieved rapid measurement with the micrometer screw feed reaching 2.0mm per revolution of the differential sleeve. Increased the thread pitch through high-precision thread processing and evaluation techniques with a spacing of 2.0mm.

● Hold with one hand to calculate the measurement time for continuously measuring 6 segments of workpieces starting from a small diameter. Compared to traditional micrometers, the positioning and measurement times can be reduced by approximately 76%* and 58%* respectively. *Survey of sampling operations.

● Utilizes a ratchet sleeve mechanism, ensuring a reliable measurement with no fluctuation even for those not accustomed to single-handed measurement. Both the differential sleeve and the speed control device can operate with a ratchet, achieving stable measurement through the minute vibration of the micrometer screw's axis. The pressure state can also be confirmed audibly, and the ratchet on the speed control device facilitates quick feed of the micrometer screw.

Function

Origin Setting:

(ABS Measurement System)

Press the ORIGIN button, at the current micrometer screw position

Reset ABS origin. Can be set according to different dimensions.

Origin Value.

Set to Zero

(INC Incremental Measurement System)

Briefly press the ZERO/ABS button, on the current micrometer screw

The location setting is displayed as zero, switch to incremental measurement.

Quantity mode (INC), hold the button to reset to ABS measurement

Pattern

Data Hold: Press the Hold button to freeze the current value on the display screen.

A feature for poor visibility conditions.

Prior to recording the reading, the instrument must be removed from the workpiece.

The measurement at the time of descaling is very useful.

Feature Lock: This feature allows for locking the origin (origin setup) function

With zeroing (set to zero) function, to prevent these points from being accidentally

Reset.

Automatic Power Supply:

Open/Close

If not used for about 20 minutes, the LCD display will...

The reading on the display will disappear, but the origin is saved.

Adjust the micrometer screw to read the display on the LCD screen.

Reemerging.

Data Output: Micrometers with this feature have an output port.

Used for transferring measurement data to statistical process control

(SPC) System.

* Applies only to MDE-MX models.

Error Alert: If there is an overflow on the LCD screen, or if the calculation

Error, error message appears on the LCD screen.

Measurement function has been stopped. This prevents the instrument from providing incorrect readings.

Misread values. When the battery voltage falls below a certain level, the measurement

Battery voltage low alert prior to normal operation.

The signaler will appear to remind users to replace the battery.
