Employees (operators) wearing synthetic clothing and moving around easily generate static discharge. Additionally, the friction and stirring between packaging products or handling equipment and the air in high-temperature rooms also produce static electricity. The static electricity can easily cause electronic components to break down and burn, affecting the accuracy of detection equipment and instruments, and can also cause computer systems to malfunction. The sparks generated by static electricity are sufficient to ignite and explode flammable and explosive gases such as natural gas, oil, and alcohol. Therefore, proper grounding is required for equipment, containers, and pipelines that are prone to static electricity generation, as well as for production processes that are prone to static electricity. Grounding refers to the electrical connection between a specific point in a system, device, or equipment and the local ground (earth). Therefore, the smaller the resistance, the faster the current flows, and the higher the level (or safer) of the equipment (or grade) that can be protected. Moreover, good grounding can effectively reduce static noise in computer systems caused by potential variations.

Types of grounding: working grounding, protective grounding, anti-static grounding, lightning protection grounding, redundant grounding, equipotential grounding, shielding grounding, signal grounding for electronic equipment, power grounding for electronic equipment, etc.

In accordance with international and domestic standards: The static grounding resistance values (earth resistance values) are divided into three grades:

        ①.≤1Ω; ②.≤4Ω; ③.≤10Ω;

General Requirements:

Communication Worksite: ≤4Ω

Safety Protection Resistance: ≤4Ω

Anti-static grounding: ≤4Ω

Lightning Protection and Grounding: ≤10Ω

The factory or laboratory can choose the appropriate grounding resistance value based on their own environmental requirements.

Recommendation: The ground resistance value for general factories can be required to be ≤10Ω (but if all equipment needs to be connected, the ground resistance value should be ≤4Ω). For example, in chemical factories (manufacturing hazardous chemicals) and factories producing and processing flammable and explosive gases, the ground resistance value should be required to be ≤4Ω or higher. For electronic factories, semiconductor factories, inspection laboratories, and computer systems (cleanrooms above 100级, with electronic components having withstand voltages not exceeding 100V), the ground resistance value should be required to be ≤4Ω or higher.
