Overview

The spiral motion and self-rotation cause the material to generate compound movement within the cone, primarily resulting in four types of motion:

The spiral rotates along the wall, causing the material to move in a circular motion along the conical wall.

2. The spiral rotation causes the material to ascend along the spiral from the conical base.

3. The spiral's compound motion of rotation and self-rotation absorbs some material into the spiral cylindrical surface, while the centrifugal force from the spiral's self-rotation causes part of the material within the spiral cylindrical surface to be radially discharged towards the cone.

4. Ascending materials descend under their own gravitational force. The four movements—convection, shearing, diffusion—within the mixer produce, resulting in rapid and even mixing.

Application Fields

The GHJ vertical high-speed mixer consists of a bottom feeding blade and a high-speed shredding blade. The feeding blade continuously feeds the bottom material upwards along the cylinder wall.

Agricultural sector: mixing in the production of pesticides, fertilizers, feed, and various additives.

◆ Food Industry: A mixture of wheat flour, grains, milk powder, spices, coffee, monosodium glutamate, salt, etc.

Chemical Industry: A blend of industries including pharmaceuticals, cosmetics, detergents, paints, resins, glass silicon, pigments, plastics, additives, etc.

High-speed granule pulp thoroughly crushes the material delivered by the pulp leaf. It creates a vortex-like circulation of the material, achieving uniform mixing in a shorter period of time.

Performance Features

The machine is suitable for solid-powder (powder particle size 300-2000um) mixing and solid-powder-liquid mixing (with liquid content <15%). It features a special jacketed design and can also be used as a drying equipment.

Our unique dual-stage, dual-axis output reducer ensures compact structure, attractive appearance, and easy operation.

◆ The conical drum body features an optimal taper to ensure smooth material flow and quick discharge without any residue.

The internal structure design of the equipment is uniquely crafted, ensuring reliable operation of single helix products and convenient maintenance.

Fast mixing speed, typically requiring only about 10 minutes for powder mixing.

◆ Manual, electric, and pneumatic discharge methods are available for your selection.

Operating Principle

The rapid self-rotation of the spiral shaft within the twin-screw cylinder elevates the material upwards, forming a helical物流 along the cylinder wall from bottom to top. Simultaneously, the rotating arm drives the spiral shaft to rotate, causing materials outside the spiral shaft to enter the helical envelope to varying degrees. Some materials are elevated out of place, while others are ejected from the helix, thus achieving continuous material renewal and diffusion. The materials elevated to the top converge into a central depression, creating a downward flow of material to fill the bottom void, thereby forming a convectional cycle. Due to the combined flow of materials up and down, the materials are uniformly mixed in a short period, resulting in high mixing efficiency.
