Nanjing Mini Ultra-Pure Water Purifier Price, Quankun Environmental Protection, Manufacturer of Ultra-Pure Water Purifiers, Modular Design
An economical ultra-pure water system, featuring high intelligence, easy operation, compact size, and simple maintenance. Widely used for pure water supply in laboratory fundamental experiments, atomic absorption spectrometry (AAS), atomic fluorescence, general chemistry, and inductively coupled plasma spectrometers, etc.
Water Quality of Product:
RO: Source Water Conductivity * 2% (Second Stage Reverse Osmosis Conductivity < 5 us/cm) @ 25℃
Pure Water: Conductivity < 0.2 us/cm
3.UP：18.25 MΩ•cm
4.TOC：<20ppb
5. Microorganisms: <1 cfu/ml
Nanjing Mini Ultra-Pure Water System Price, Quankun Environmental Protection, Ultra-Pure Water System Manufacturer, Modular Design
Product Configuration Technical Features:
The ultra-pure water equipment is designed with the following special process configurations, adhering to the design philosophy of "strong raw water adaptability, high yield, extended consumable lifespan, excellent and stable finished water quality, adjustable system operating parameters, and compatibility with precision instruments such as biochemical analyzers":
"High adaptability and large water production capacity of raw water: inevitably increases the volume and processing capacity of the pretreatment, reverse osmosis, and post-treatment ultra-pure sections. The pretreatment section of the pure water equipment comes standard with 20" filter cores, and after treatment, tap water from ordinary cities can meet the water input requirements for the subsequent reverse osmosis section. For poor quality tap water or turbid groundwater, a softening filter with self-cleaning function is configured. This way, the ultra-pure water equipment can almost adapt to all types of water sources; in the reverse osmosis section, the ultra-pure water equipment is equipped with imported high desalination rate (desalination rate >99%) reverse osmosis membranes, with one membrane producing 50 liters or 125 liters of water per hour (this is achieved without the need for串联 multiple ordinary desalination rate household-grade reverse osmosis membranes)."
"Extended Consumables Life: The pretreatment section comes standard with a 20" active filter cartridge, and with a softening filter equipped with an auto-clean function, there's almost no need to replace the pretreatment consumables; simply periodic backwashing of the filter media is required. The reverse osmosis section, utilizing high desalination reverse osmosis membranes in the ultra-pure water system, boasts a lifespan 3 to 4 times that of standard residential reverse osmosis membranes. The post-treatment ultra-pure section features a resin filling capacity for the ultra-pure water system that is about 3-5 times that of typical ultra-pure water machines. Coupled with the high desalination rate of the reverse osmosis section, the resulting pure water (the input to the post-treatment ultra-pure section) has superior quality, which extends the service life of the consumables in the Taipingma ultra-pure water system's purification unit."
"Superior and stable product water quality, adjustable system operating parameters: The excellent and stable quality of the product water from ultra-pure water systems is attributed to the high-quality and stable water produced by the reverse osmosis section (pure water). Only when high-quality and stable pure water is fed into the subsequent ultra-pure purification section can the final product water maintain its excellent and stable quality. The production of high-quality pure water in the reverse osmosis section depends on the following conditions: water quality meets standards, the quality of the reverse osmosis membrane is excellent, and the system configuration (operating pressure, flow rate, etc.) is reasonable. Ultra-pure water systems, whether equipped with a 20" activated carbon filter or a combination with an automatic cleaning softener, are designed to provide qualified feed water to the reverse osmosis system. Additionally, the high desalination rate industrial-grade reverse osmosis membranes used in the ultra-pure water systems are also of excellent quality. The systems are equipped with two pressure gauges, two flowmeters, and one system pressure regulating valve, allowing for dynamic adjustment of system operating parameters and water production flow rate based on different raw water qualities and equipment conditions. This ensures the equipment operates optimally, continuously producing high-quality product water."
"Suitable for Precision Instrumentation: General biochemical analyzers require high-quality ultra-pure water systems (water with a resistivity of over 10 MΩ.cm is sufficient), but consume a large volume of water. Taipingma's ultra-pure water equipment meets both the water output and quality requirements for biochemical analyzer配套. Additionally, to meet the varying water supply conditions of different biochemical analyzers, the ultra-pure water equipment can be equipped with either a fully enclosed pressure tank or a stainless steel or PE tank with an immersion-type UV sterilization unit. Adding a constant pressure water supply system can enable multiple laboratories to receive quality-assured centralized water supply."
Ultra-pure water equipment, in addition to the above targeted design, includes: integration of pretreatment, reverse osmosis, and post-treatment into a cabinet with swivel casters for easy installation and maintenance, with scientifically designed piping structure; an imported single-chip microcomputer CPU for full automatic control, with an audible and visual fault self-checking alarm system, an LCD screen for real-time water quality display, an ergonomic human-machine interface, fully waterproof safety stainless steel water collection buttons, and other technical features.
