I. Basic Definitions and Classification

A cantilever racking system is a storage equipment specifically designed for long materials, circular materials, sheets, pipes, and irregularly shaped goods. Its core structure, formed by the combination of columns and cantilevers, creates an extended storage space, suitable for various industry scenarios. Based on the cantilever style and load-bearing capacity, it can be further divided into the following types:

By cantilever style: Single-sided cantilever (wall-mounted, one-side access) and double-sided cantilever (placed in the middle of the warehouse, both-side access).

By load-bearing capacity: Light-duty (single arm load ≤ 100kg), Medium-duty (single arm load 200-800kg), Heavy-duty (single arm load ≥800kg, up to 5000kg).

Section 2: Core Structure and Materials

Pole System

Material: Made of H-shaped steel or cold-rolled steel, joined by welding two pieces of C-shaped steel together, enhancing load-bearing capacity.

Design Features: Pre-fabricated columns with double rows of holes, 100mm spacing between holes, allowing cantilevers to be adjusted up and down at 100mm intervals to accommodate varying cargo heights.

Enhanced Stability: Equipped with a back pull structure (such as flat iron back pull), the column pieces are secured by special pullers to prevent deformation.

Cantilever assembly

Material: Square tube, H-beam, or cold-rolled section steel, single arm length typically ≤1.5 meters, ensuring structural rigidity.

Connection Method: The cantilever and column are connected via plug-in or bolted joints, facilitating disassembly and adjustment.

Anti-slip Design: Welded anti-slip guard at the end of the cantilever to prevent goods from sliding off.

Base and auxiliary components

Base: Made of cold-rolled steel or H-beam, equipped with a base plate for ground fixation, ensuring overall stability.

Additional Configurations: Optional steel grating, wooden board, or mesh as deck plates to enhance space utilization; equipped with safety features such as guardrails and stairs.

Section 3: Features and Advantages

Efficient Storage for Long-Shaped Materials

The cantilever design allows for easy storage of long items like steel pipes, profiles, wood, etc., eliminating the storage limitations of traditional shelves.

Ring materials (such as cables, steel rings) can be suspended through cantilever gaps, saving space.

Flexible adjustment and scalability

The modular structure allows for adjustable cantilever length, floor height, and unit quantity, accommodating various warehouse layouts.

Modular design facilitates disassembly, transportation, and reassembly, reducing long-term usage costs.

High load-bearing capacity and stability

Heavy-duty shelving features a single arm bearing capacity of up to 5000kg, with columns capable of withstanding 2000-3000kg of pressure, meeting the storage needs for heavy goods.

The back pull structure and double row hole design enhance overall rigidity, preventing the shelf from tilting or deforming.

Space utilization optimization

Vertical分层storage can increase warehouse space utilization by over 60%, particularly suitable for warehouses with a height of 4 meters or more.

The double-sided cantilever design allows for dual-side access, reducing aisle occupation and enhancing operational efficiency.

Compatible with various access methods

Supports forklifts, cranes, or manual handling; paired with stackers, it enables automated operations to enhance logistics efficiency.

Section 4: Application Scenarios and Industry Compatibility

Manufacturing

Machine Manufacturing: Store long shafts, profiles, and other components for easy assembly and distribution.

Automotive Parts: Store heavy components like drive shafts, tires, etc., saving space and easy to manage.

Building materials and logistics industry

Building Materials Warehouse: Stores materials like rebars, wood, PVC pipes, etc., in long strips to minimize on-site disarray.

Logistics Center: Stores furniture, electronics, and other large goods, optimizing warehouse space layout.

Special Environment Applications

Refrigerated Warehouse: Made of materials that can withstand -40°C temperatures, ensuring stability of goods.

Mining and Energy: Store long-distance pipelines and cables, ensuring orderly management of critical materials.

Other Industries

Agriculture: Store irrigation pipes and long agricultural equipment to enhance management efficiency.

Aluminum and Metal Products: Store long aluminum extrusions and stainless steel pipes, offering open storage environment.
