| Serial Number | Project | Parameters |
| 1 | Processed Hole Diameter | Φ20-Φ300mm (optional in other sizes) |
| 2 | Spindle Drive | High and low speed transmission + CVT |
| 3 | Spindle Speed | 10-350RPM |
| 4 | Stroke method | Servo Motor |
| 5 | Stroke Speed | 40m/min |
| 6 | Stroke Length | 1000m m |
| 7 | Feeding method | Servo Motor + Customized Screw |
| 8 | Feed Resolution | 1um |
| 9 | Cooling System | Flow rate: 50/min Capacity: ≥300L |
| 10 | Standard fixture holds outer diameter | 28-380mm |
| 11 | Dimensions and appearance | 4804mm* 940mm*1700mm |
| 12 | Machine Tool Weight | 2.8 tons |
