Full steel lab benches, as the core equipment of laboratories, stand out due to their steel-based structure and modular design, making them the preferred choice for laboratories in fields such as chemistry, biology, and pharmaceuticals. Their core value lies inStability, safety, functionality, and environmental friendlinessA deep integration is discussed, with the following analysis from four major dimensions:

Material and Craftsmanship: The Performance Foundation of Full Steel Structure

1. Main Frame
2. Utilizing cold-rolled steel sheets (thickness ≥1.2mm) treated with acid cleaning and phosphatizing, coated with electrostatic epoxy resin for triple protection.

• Corrosion-resistantPickling and phosphating to remove the oxide layer on steel surfaces, epoxy resin coating to isolate moisture and chemical reagent corrosion, acid and alkali resistance up to pH 1-14.
• Fire-resistant and seismic-resistantThe melting point of the steel exceeds 1500°C, and when paired with a reinforced frame (≥40×60mm rectangular steel tube), it can withstand an 8-level earthquake impact.
• Load-bearing capacityStatic load-bearing capacity exceeds 250kg/m². Heavy-duty instrument laboratories can be customized with double-layer support structures or reinforced floor plates to meet the placement requirements of centrifuges, ultra-low-temperature freezers, and other equipment.

1. Countertop Material
2. Match corrosion-resistant materials based on the type of experiment:

• Epoxy resin boardResistant to strong acids and alkalis (such as concentrated sulfuric acid), with a dense and poreless surface to prevent liquid penetration.
• Ceramic PanelsWithstanding high temperatures (≥1200℃), suitable for scenarios such as muffle furnaces and high-temperature reaction vessels.
• Anti-static work surfaceSurface resistance: 10⁶-10⁹ Ω, suitable for electronic component testing and microfluidic chip experiments.

II. Functional Design: Fusion of Modularization and Intelligence

• Modular Expandable Storage SystemThe cabinet is constructed with seamless welding technology to prevent dust accumulation in gaps; the drawer slides feature a three-section silent design, supporting a load of ≥50kg.
• Reagent RackAdjustable height (50mm per step), equipped with splash-proof socket (IP65 protection rating) and local exhaust system to reduce accumulation of volatile reagents.
• Water, electricity, and gas integratedPP material sink with copper laboratory faucet, supports hot and cold water switch; cabinet预留gas outlet (such as nitrogen, argon) and power outlet (16A/250V), meets complex experimental requirements.
• Smartened-up Environmental Monitoring UpgradeOptional humidity and temperature sensor, real-time data feedback to Laboratory Information Management System (LIMS).
• Remote ControlAdjust exhaust cabinet airspeed and lighting brightness via the mobile app to enhance energy efficiency.
• Safety AlertIntegrated gas leak detection module, automatically triggers audible and visual alarms and shuts off the gas supply upon exceeding the limit.
