Applicable to: Hardware Parts, Auto & Motorcycle Parts.
Features: Wash and dry in one cycle, compatible with automated unloading and loading system.
Process: Material In, Rotating Spray Wash, Rotating Dry, Material Out.
| Model | HWQ | ||||
| Dimensions | 1800×1000 ×1800 | 1800×1100 ×1900 | 1900×1200 ×2000 | 1900×1200 ×2000 | 2200×1300 ×2400 |
| Practical Cleaning Dimensions MAX | 300×200 | 400×300 | 500×400 | 600×500 | 800×600 |
| Rated Voltage | 380/220V±10% 50/60Hz | ||||
| Gas Source Pressure Mpa | ≥4.5 | ||||
| Power Consumption: 380/220V | 6/1 | 10/1 | 14/2 | 20/2 | 38/3 |
| One-time water injection amount M3 | 0.1 | 0.12 | 0.16 | 0.2 | 0.25 |
| Cleaning Capacity T (S) | Standard work rhythm: 120 seconds (adjustable from 3-900) | ||||
| Body Weight: Kg | 350 | 450 | 650 | ||
