n Supports platform remote configuration for low-power mode, featuring both power-saving and ultra-power-saving operating modes

n Supports Hikvision Interconnect Integration

n SupportLTE-TDD/LTE-FDD 4GWireless network transmission, external antenna

n Supports intelligent fill light function, supports white light30 mInfrared30 m

n 1An integrated microphone,1An integrated speaker, supporting two-way voice communication

n SupportedMicroSD/MicroSDHC/MicroSDXCCard, maximum512 GB

n Dome camera meetsIP66Waterproof and dustproof design

n SupportedAOVFeatures, supported24Hourly light storage, effectively reducing electricity consumption

n Detachable battery clip, built-in32WHBatteries, compatibleAOVMode7All-day battery life

n Supports external plugNano SIMCard

n Built-in telecom and Unicom dualSIMCard

Basic Parameters

Sensor Type

1/3" Progressive Scan CMOS

Lowest Illuminance

Color:0.005 Lux

Backlight Compensation

Support

Wide Dynamic Range

Digital Wide Dynamic Range

Strong Light Suppression

Support

3D Noise Reduction

Support

Lens

Focal Length

4 mm

Field of View

4 mmHorizontal Field of View:79°Vertical Field of View:43°Diagonal field of view angle:93°

Maximum Aperture Number

F1.28

Fill Light

Grow light type

Infrared Lighting, White Lighting Compensation

Supplementary Light Distance

Up to the furthest point30 m

Anti-overexposure protection

Supported

Wavelength Range

Infrared850 nm

Tripod

Number of preset points

300Unit

Horizontal Range

0°~340°

Vertical range

Vertical0°-80°

Horizontal Speed

Highest level25°/S

Vertical speed

Vertical Maximum20°/S

Video

Maximum Resolution

2560 × 1440

Main Stream Frame Rate Resolution

50 Hz：12.5 fps（2560 × 1440，1920 × 1080，1280 × 720）

Video Compression Standard

H.265/H.264

Video compression bit rate

32 Kbps~8 Mbps

H.264

baseLine Profile/Main Profile/High Profile

H.265

Main Profile

Audio

Audio Compression Standards

G.711alaw

Audio Compression Bit Rate

64 Kbps（G.711alaw）

Audio Sampling Rate

8 kHz/16 kHz

Environmental Noise Filtration

Supported

Mobile Communication Parameters

Wireless Standard

LTE-TDD/LTE-FDD

Wireless Frequency Band

LTE-TDD：Band 34/38/39/40/41
LTE-FDD：Band 1/3/5/8


Image Settings

Mirror, saturation, brightness, contrast, sharpness are adjustable through the client or browser.

Interface

SD card expansion

SupportMicroSD/MicroSDHC/MicroSDXCCards, up to support512 GB

Audio

1An integrated microphone,1An integrated speaker

Event

Routine event

Motion Detection (supports human and vehicle detection)

Alarm联动

UploadSDCard, Upload Center, Video Recording, Screenshot, Sound Alarm

General Specifications

Environmental Usage Instructions

1Do not use the equipment in environments with vibration or impact, such as on vehicles, high-speed trains, ships, port cranes, and large-scale mining machinery, etc.
2Do not use the equipment in highly corrosive, strong acidic, or high salt content areas such as offshore islands, platforms, ships, chemical industries, fumigation, and coastal regions.5Within kilometers (within miles) in special corrosive environments
3Do not use the equipment in environments with strong electromagnetic interference, such as the main transmission direction of broadcast tower antennas, substation closing areas, near the transmission lines of the power grid, overhead trolleys, radar, medical nuclear magnetic resonance,4G/5G/FMHigh-frequency radiation environment near base station antennas and other strong electromagnetic interference sources
4Do not use the equipment in extreme heat, cold, dust, or prolonged high humidity conditions. Refer to the working temperature and humidity requirements.

Universal Features

Password protected, watermark technology

Power Supply

Camera Power Interface:4ChipM8Head
Current and Power Consumption: Typical Power Consumption Scenario:100 mW
Standby Power Consumption Scenario:80 mW
Maximum Power Consumption:9 W

Operating Temperature and Humidity

Turn on the supplemental light:-30 °C~40 °C, humidity less than95%(Non-Condensing)
Turn off the light fixture-30 °C~50 °C, humidity less than95%(Non-Condensing)

Material

Shell plastic

Dimensions

Product Dimensions:208 × 131.9 × 282.7 mm
Packaging Size:386 × 201 × 225 mm

Weight

Equipment Weight:600 g
Net Weight with Packaging:2100 g

Battery

Battery Storage Temperature

1Year:-20 ~ 25 °C ≤ 70% RH
3Month:-20 ~ 45 °C ≤ 70% RH
1Month:-20 ~ 60 °C ≤ 70% RH

Typical Battery Capacity

32.56‬ Wh

Battery low-temperature discharge retention rate

-20 °C：≥ 70%
-10 °C：≥ 75%
 0 °C：≥ 85%

Battery output interface

All-Purpose Power SupplyDC：9 V~12.6 V）

Battery Input Interface

Type-CMouth, maximum charge8 W（5 V/1.6 A）

Certification

EMC

Class B

Protective

Ball Camera:IP66Prevent heavy downpours
Battery Bracket:IP65

Solar Power Supply Parameters

Solar Panel Types

Monocrystalline Silicon

Solar panel conversion efficiency

>22%

Solar panel dimensions/Weight

260 × 168 × 18.8 mm

Battery Type

Li-ion Battery Pack

Battery Charging Temperature

0 °C ～ 45 °C

Battery Discharge Temperature

-20 °C ~ 55 °C

Wind Resistance Grade of Bracket

8Grade

Battery lifespan

AOVPattern7Day25 °C/3 WLoad/100%Battery Capacity

Agreement

Interface Protocol

Fluorite Cloud

Client

Hikvision Interconnect

System

Restore to factory settings

SupportRESETPress button, client restores
