n Panorama Road is a fixed-focus lens, supporting vertical orientation.7~17°Manual adjustable

n Detail road support12Optical Zoom Factor5.76 mm~69.12 mm）；16Digital X Times Zoom

n Full panoramic support up to2560 × 1440 @30 fpsHigh-definition image output

n Detail support up to2560 × 1440 @30 fpsHigh-definition picture output

n Supports high-efficiency backlight array, with the infrared beam distance reaching up to the longest detail path80 mThe panoramic road infrared beam can reach the longest distance of...30 mThe distance of white light illumination can reach up to30 mThe Panoramic Road supports intelligent lighting enhancement, switching from infrared to white light upon the approach of pedestrians or vehicles, and back to infrared when they leave.

n The device comes with an integrated microphone and speaker, supporting two-way voice communication.

n The equipment comes with a bracket, supporting both wall-mounted and suspended installation, with the bracket accommodating horizontal positioning.360°Rotary Position

n Supports dual-path area intrusion, boundary detection, entry area detection, and exit area detection; allows for setting up alarm sound and strobe lights to be activated upon deployment of defense.

n SupportRS-485Alarm in and out function, supports interconnectionAPPManual alarm output

n Support4GFeatures, built-in equipment1Zhang TelecomSIMSurface mount card, with an external connectionSIMCard slot, compatible with Hikvision InterconnectAPPPerform in-builtSIMCard recharge

n Supports PTZ pedestrian, vehicle target tracking

n Supports preset configuration points, supports scheduled tasks, one-click cruising

n SupportSVCAdaptive coding technologyROIEnhanced Encoding for Areas of Interest

n IP66Highly resistant to interference, suitable for harsh electromagnetic environments.

Basic Parameters

Sensor Type

【Panoramic View】1/2.8" Progressive Scan CMOS ; [Details]1/2.8＂ Progressive Scan CMOS

Shutter

1/30s~1/30,000 s

Lowest Illuminance

【Panoramic】Color:0.01 Lux @（F1.6, AGC ON) Black and white:0.005Lux @ (F1.6, AGC ON)，0 Lux with IR; [Details] Color:0.02Lux @ (F1.86，AGC ON),Black and white:0.005Lux @ (F1.86, AGC ON)，0 Lux with IR

Slow shutter speed

Support

Focus Mode

Semi-automatic/Manual/Automatic

Day/Night Mode Switch

AutomaticICRColor to Black

Optical Zoom

【Full View】: Not Supported
Details:12Multiple

Day/Night Switch Method

Day and Night, Auto-Toggle, Timer Switch

Backlight Compensation

Support

Strong Light Suppression

Support

3D Noise Reduction

Supported

Penetrate the fog

Support

Regional Exposure

Support

Regional Focus

Support

Image Settings

Saturation, Brightness, Contrast, Sharpness

Image parameter switch

Supported

White Balance

Automatic White Balance,Automatic White Balance Tracking,Sodium lamp,Fluorescent lamp,Indoor,Outdoor,Manual White Balance,Lock White Balance

Privacy Shield

Up to24Brick,Supports multiple color settings,Quadrilateral area

Signal-to-Noise Ratio

＞52dB

Universal Features

Mirroring, password protection, watermark technologyIPAddress Filtering

Lens

Focal Length

【Full Panorama】4mm; [Details]5.76 mm~69.12 mm，12Optical Zoom

Optical Zoom Speed

Details: Approximately3.3s

Field of View

【Panoramic View】Horizontal Field of View:93.7 °Vertical field of view:48.9 ° 【Details】Horizontal Field of View:50°-7.5°(Wide-angle~Telephoto) Vertical Field of View:31°-4°Wide-angle~Telescopic (望远）

Maximum Aperture Count

【Full Panorama】F1.6; [Details]F1.86~2.65

Fill Light

Infrared Beam Distance

Panoramic: Infrared30mWhite light30m
Details: Infrared80m

Tripod

Horizontal speed

Horizontal keying speed:0.1°-35°/sSpeed adjustable; preset level point speed:35°/s

Horizontal Range

350°

Vertical Range

-5°-90°

Vertical speed

Vertical keying speed:0.1°-30°/s,Speed adjustable; Vertical preset point speed:30°/s

Ratio Magnification

Support

Pre-set Points Count

300None

Cruise Scan

8Yards, each with the option to add32A pre-set point

Power failure memory

Support

Watch Function

Pre-set points,Cruise Scan

3D positioning

Support

Azimuth information display

Support

Pre-set Point Video Freeze

Supported

Scheduled Task

Pre-set points,Cruise Scan,Ball Camera Restart,Ball Camera Verification,Shut down

Video

Digital Zoom

16Multiple

Maximum Image Size

【Panoramic View】2560 ×1440[Details]2560 ×1440

Stream Type

Main Stream, Sub Stream, Third Stream

Main stream frame rate resolution

【Full Panorama】
50 Hz：25 fps（2560 × 1440，1920 × 1080，1280 × 720）
60 Hz：30 fps（2560 × 1440，1920 × 1080，1280 × 720）
Details
50 Hz：25 fps（2560 × 1440，1920 × 1080，1280 × 720）
60 Hz：30 fps（2560 × 1440，1920 × 1080，1280 × 720）

Substream frame rate resolution

【Full Panorama】
1280*720
640*480
640*360
Default:640*360
Details
1280*720
640*480
640*360
Default:640*360

Third stream frame rate resolution

【Full Panorama】
704x576
640×480
352 x 288
Default:704x576
[Details]
704x576
640×480
352 x 288
Default:704x576

Video Compression Standard

H.265,H.264,MJPEG

Video Compression Bitrate

32 kbps~16384 kbps

H.264

baseline Profile,Main Profile,High Profile

H.265

Main Profile

Smart 264

Supported

Smart 265

Support

SVC

Support

ROI

Supported

Audio

Audio Compression Standards

G.722.1,G.711ulaw,G.711alaw,MP2L2,G.726,AAC,PCM,MP3

Audio Compression Bitrate

MP2L2：32kbps，40kbps，48kbps，56kbps，64kbps，80kbps，96kbps，112kbps，128kbps，144kbps，160kbps AAC  ：16kbps，32kbps，64kbps MP3  ：8kbps，16kbps，32kbps，40kbps，48kbps，56kbps，64kbps，80kbps，96kbps，112kbps，128kbps，144kbps，160kbps

Audio Sampling Rate

MP2L2:16kHz,32kHz,44.1kHz,48kHz，AAC:16kHz,32kHz,44.1kHz,48kHz，PCM:8kHz,16kHz,32kHz,44.1kHz,48kHz，MP3: 8kHz,16kHz,32kHz,44.1kHz,48kHz

Environmental Noise Filtration

Supported

Smart

Routine event

Motion Detection,Alarm Input,Alarm Output,Obstruction Alarm,Abnormality

Smart Event

Area Intrusion Detection,Boundary Detection,Enter Area Detection,Leave Area Detection,Audio Anomaly Detection

Smart Recording

Offline Resumption and Smart Post-Search

Alarm联动

Pre-set points,Cruise Scan,SDVideo recording card,Email,Upload Center,UploadFTP,NASVideo

Internet

Network Storage

NAS (NFS, SMB/ CIFS)

Support Agreement

IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP/IP,UDP,IGMP,ICMP,DHCP,Bonjour

Interface Protocol

Support for Foscam integration

Maximum number of flow paths

6Road

User Management

32An

Safety Management

Authorized username and password,andMACAddress Binding,HTTPSEncrypted,IEEE 802.1xNetwork Access Control,IPAddress Filtering

Client

Hikvision (Mobile App)

Browser

IE11，Chrome80+，Firefox80+，Safari13+，Edge89+

Mobile Communication Parameters

Wireless Frequency Band

LTE-TDD：Band 34/38/39/40/41
LTE-FDD：Band 1/3/5/8

Wireless Standard

LTE-TDD/LTE-FDD

Interface

Built-in microphone

Support

Built-in speaker

Supported

Alarm

1Road alert input1Road alarm output

RS-485

Support

Network Interface

RJ45Network port,Adaptive10M/100MInternet Data

SD card expansion

Built-inMicro SDCard slot, supportsMicro SD/Micro SDHC/Micro SDXCCard (Max Supported)512GB）

General Specifications

Power Supply

DC：12V，2 A
Maximum Power Consumption:15W

Environmental Usage Instructions

1Do not operate the equipment in environments with vibration or shock, such as on vehicles, high-speed trains, ships, port cranes, and large-scale mining machinery, etc.
2Do not use the equipment in areas with severe corrosion, strong acids, or high salt content, such as offshore islands, platforms, vessels, chemical industries, fumigation, and coastal areas.5Within kilometers) in special corrosive environments;
3Do not use the equipment in environments with strong electromagnetic interference, such as the main transmission direction of broadcast tower antennas, substation closing areas, near the transmission lines of the power grid, overhead contact wires, radar, medical nuclear magnetic resonance,4G/5G/FMHigh-frequency radiation environment near base station antennas and other strong electromagnetic interference sources.
4Do not use the equipment in extremely hot, cold, dusty, or prolonged high humidity environments; refer to the working temperature and humidity requirements.

Operating Temperature and Humidity

-30 ℃~50 ℃, humidity less than95%Non-condensable

Restore Factory Settings

Support

Material

PC

Dimensions

311.5×223.5×156 mm

Weight

1.37 kg

Certification

Protective

IP66 Suited for complex electromagnetic environments, featuring high immunity to interference
